Trustly

Logo

Info

The Trustly online bank transfer is convenient for the customer and secure for the merchant. This payment method enables customers to be addressed who have an account at one of 30 banks in Sweden, Finland, Denmark and Spain.

Type

Payments by Online Bank Transfer

Format

Description

a

alphabetical

as

alphabetical with special characters

n

numeric

an

alphanumeric

ans

alphanumeric with special characters

ns

numeric with special characters

bool

boolean expression (true or false)

3

fixed length with 3 digits/characters

..3

variable length with maximum 3 digits/characters

enum

enumeration of allowed values

dttm

ISODateTime (YYYY-MM-DDThh:mm:ss)

Abbreviation

Description

Comment

CND

condition

M

mandatory

If a parameter is mandatory, then it must be present

O

optional

If a parameter is optional, then it can be present, but it is not required

C

conditional

If a parameter is conditional, then there is a conditional rule which specifies whether it is mandatory or optional

MerchantID

ans..30

M

MerchantID, assigned by Computop. Additionally this parameter has to be passed in plain language too.

TransID

ans..64

M

TransactionID provided by you which should be unique for each payment

refnr

ans..30

O

Merchant’s unique reference number

Amount

n..10

M

Amount in the smallest currency unit (e.g. EUR Cent). Please contact the Computop Helpdesk, if you want to capture amounts <100 (smallest currency unit).

Currency

a3

M

Currency, three digits DIN / ISO 4217. Only BAM, BGN, CZK, EEK, EUR, GBP, HRK, HUF, LTL, LVL, PLN, RON and USD permissible; the currency must match CountryCode. Please find an overview here: A1 Currency table

MAC

an64

M

Hash Message Authentication Code (HMAC) with SHA-256 algorithm. Details can be found here:

• HMAC Authentication (Request)

• HMAC Authentication (Notify)

OrderDesc

ans..768

M

Description of goods and prices. Intended purpose on the statement of account.

URLSuccess

ans..256

M

Complete URL which calls up Paygate if payment has been successful. The URL may be called up only via port 443. This URL may not contain parameters: In order to exchange values between Paygate and shop, please use the parameter UserData.

Common notes:

• We recommend to use parameter "response=encrypt" to get an encrypted response by Paygate

• However, fraudster may just copy the encrypted DATA-element which are sent to URLFailure and send the DATA to URLSuccess/URLNotify. Therefore ensure to check the "code"-value which indicates success/failure of the action. Only a result of "code=00000000" should be considered successful.

URLFailure

ans..256

M

Complete URL which calls up Paygate if payment has been unsuccessful. The URL may be called up only via port 443. This URL may not contain parameters: In order to exchange values between Paygate and shop, please use the parameter UserData.

Common notes:

• We recommend to use parameter "response=encrypt" to get an encrypted response by Paygate

• However, fraudster may just copy the encrypted DATA-element which are sent to URLFailure and send the DATA to URLSuccess/URLNotify. Therefore ensure to check the "code"-value which indicates success/failure of the action. Only a result of "code=00000000" should be considered successful.

Response

a7

O

Status response sent by Paygate to URLSuccess and URLFailure, should be encrypted. For this purpose, transmit Response=encrypt parameter.

URLNotify

ans..256

M

Complete URL which Paygate calls up in order to notify the shop about the payment result. The URL may be called up only via port 443. It may not contain parameters: Use the UserDataparameter instead.

Common notes:

• Before follow-up actions (capture / credit / reversal) are carried out on an existing transaction, the first Notify must have been answered by the shop.

• Fraudster may just copy the encrypted DATA-element which are sent to URLFailure and send the DATA to URLSuccess/URLNotify. Therefore ensure to check the "code"-value which indicates success/failure of the action. Only a result of "code=00000000" should be considered successful.

UserData

ans..1024

O

If specified at request, Paygate forwards the parameter with the payment result to the shop.

ReqId

ans..32

O

To avoid double payments or actions (e.g. by ETM), enter an alphanumeric value which identifies your transaction and may be assigned only once. If the transaction or action is submitted again with the same ReqID, Computop Paygate will not carry out the payment or new action, but will just return the status of the original transaction or action.

Please note that the Computop Paygate must have a finalized transaction status for the first initial action (authentication/authorisation). This does not apply to 3-D Secure authentications that are terminated by a timeout. The 3-D Secure Timeout status does not count as a completed status in which the ReqID functionality on Paygate does not take effect. Submissions with identical ReqID for an open status will be processed regularly.

Notice: Please note that a ReqID is only valid for 12 month, then it gets deleted at the Paygate.

IPAddr

ans..15

O

Customer´s IP address in IPv4 or IPv6 format

FirstName

ans..100

M

First name of the customer

LastName

ans..100

M

Last name of the customer

Email

ans..100

M

Customer’s email

MobileNo

n..20

O

Customer’s mobile telephone number

CountryCode

a2

O

Two characters country code according to ISO 3166

Language

ans..5

O

Language, e.g. de_DE, en_US, sv_SE

SocialSecurityNumber

ans..20

O

Social security number, identity card number etc.

CustomerId

ans..30

O

Customer number

URLTemplate

ans..256

O

URL of your individual layout for the payment form.

This template page can be self-designed but must be compliant to the security guidelins of Trustly.

-     all pictures need an absolute URL

-     all links must start with https

-     tags like script, iframe, frame, frameset, object, applet, etc are not allowed.

The page must contain the following tag at any place.

<!—TRUSTLY-PAYMENT-PAGE-GOES-HERE >

At this place the Trustly transaction page (600x600px) will be displayed.

Plain

ans..50

O

A single value to be set by the merchant to return some information unencrypted in response/notify, e.g. the MID.

"Plain"-parameter is part of encrypted "Data" in Computop Paygate and therefore protected against manipulation.

Custom

ans..1024

O

"Custom"-parameter is added to the request data before encryption and is part of encrypted "Data" in Computop Paygate request. By this they are protected against manipulation by a consumer.

The Custom-value is added to the Computop Paygate response in plain text and the "|" is replaced by a "&". By this you can put a single value into Custom-parameter and get multiple key-value-pairs back in response for your own purpose.

Please find a sample here: Custom

mid

ans..30

M

MerchantID, assigned by Computop

PayID

an32

M

ID assigned by Paygate for the payment, e.g. for referencing in batch files as well as for capture or credit request.

XID

an32

M

ID for all single transactions (authorisation, capture, credit note) for one payment assigned by Paygate

TransID

ans..64

M

TransactionID provided by you which should be unique for each payment

Status

a..50

M

OK – is reported by Paygate via URLSuccess redirect and also as a separate notify

FAILED – is reported by Paygate via URLFailure redirect and also as a separate notify

AUTHORIZE_REQUEST – is reported in the first step via redirect to the URLSuccess, based on this response the payment must be defined as open.

Only the separate Notify reports the final status of the payment. If you want to receive the first open status (URLSuccess Redirect) additionally via URLNotify, please inform our Computop Helpdesk.

If this function is active, you will receive two notifies, the initial AUTHORIZE_REQUEST and later with the final status.

Description

ans..1024

M

Further details in the event that payment is rejected. Please do not use the Description but the Code parameter for the transaction status analysis!

Code

an8

M

Error code according to Paygate Response Codes (A4 Error codes)

MAC

an64

M

Hash Message Authentication Code (HMAC) with SHA-256 algorithm. Details can be found here:

• HMAC Authentication (Request)

• HMAC Authentication (Notify)

UserData

ans..1024

O

If specified at request, Paygate forwards the parameter with the payment result to the shop.

Plain

ans..50

O

A single value to be set by the merchant to return some information unencrypted in response/notify, e.g. the MID.

"Plain"-parameter is part of encrypted "Data" in Computop Paygate and therefore protected against manipulation.

Custom

ans..1024

O

"Custom"-parameter is added to the request data before encryption and is part of encrypted "Data" in Computop Paygate request. By this they are protected against manipulation by a consumer.

The Custom-value is added to the Computop Paygate response in plain text and the "|" is replaced by a "&". By this you can put a single value into Custom-parameter and get multiple key-value-pairs back in response for your own purpose.

Please find a sample here: Custom

AccountId

ans..30

O

Unique name/number to identify the specific customer account

Match

n1

O

0=not verified; 1=verified

AccClearingHouse

ans..50

O

Clearing house for that account

AccOwner

ans..55

O

Name of account holder

AccBank

ans..27

O

Name of the bank

AccDescriptor

ans..100

O

Additional text for identifying the customer

IBAN

n8

O

Last digits of IBAN/ account number

UserId

ans..30

O

Unique name/number for identifying the respective customers

AddrStreet

ans..100

O

Customer’s street name and house number

AddrZip

ans..10

O

Postcode of the customer

AddrCity

ans..30

O

Town/city of the customer

MerchantID

ans..30

M

MerchantID, assigned by Computop. Additionally this parameter has to be passed in plain language too.

PayID

an32

M

ID assigned by Paygate for the payment to be credited

TransID

ans..64

M

TransactionID provided by you which should be unique for each payment

Amount

n..10

M

Amount in the smallest currency unit (e.g. EUR Cent). Please contact the Computop Helpdesk, if you want to capture amounts <100 (smallest currency unit).

Currency

a3

M

Currency, three digits DIN / ISO 4217, e.g. EUR, USD, GBP. Please find an overview here: A1 Currency table

MAC

an64

M

Hash Message Authentication Code (HMAC) with SHA-256 algorithm. Details can be found here:

• HMAC Authentication (Request)

• HMAC Authentication (Notify)

ReqId

ans..32

O

To avoid double payments or actions (e.g. by ETM), enter an alphanumeric value which identifies your transaction and may be assigned only once. If the transaction or action is submitted again with the same ReqID, Computop Paygate will not carry out the payment or new action, but will just return the status of the original transaction or action.

Please note that the Computop Paygate must have a finalized transaction status for the first initial action (authentication/authorisation). This does not apply to 3-D Secure authentications that are terminated by a timeout. The 3-D Secure Timeout status does not count as a completed status in which the ReqID functionality on Paygate does not take effect. Submissions with identical ReqID for an open status will be processed regularly.

Notice: Please note that a ReqID is only valid for 12 month, then it gets deleted at the Paygate.

mid

ans..30

M

MerchantID, assigned by Computop

PayID

an32

M

ID assigned by Paygate for the payment, e.g. for referencing in batch files as well as for capture or credit request.

XID

an32

M

ID for all single transactions (authorisation, capture, credit note) for one payment assigned by Paygate

TransID

ans..64

M

TransactionID provided by you which should be unique for each payment

Status

a..50

M

OK (URLSuccess) or FAILED (URLFailure)

Description

ans..1024

M

Further details in the event that payment is rejected. Please do not use the Description but the Code parameter for the transaction status analysis!

Code

an8

M

Error code according to Paygate Response Codes (A4 Error codes)

Action

Version

Description

Credit

1.0 / 2.0

Standard version without return of parameter Code

1.x / 2.x

with RefNr (valid for all versions other than 1.0)

Type

a..11

M

HEAD for Header, FOOT for Footer, Trustly for Trustly

Action

a..20

M

The parameter Action defines the type of transaction:

Credit

Amount

n..10

M

Amount in the smallest currency unit (e.g. EUR Cent). Please contact the Computop Helpdesk, if you want to capture amounts <100 (smallest currency unit).

Currency

a3

M

Currency, three digits DIN / ISO 4217, e.g. EUR, USD, GBP. Please find an overview here: A1 Currency table

TransID

ans..64

M

TransactionID provided by you which should be unique for each payment

refnr

ans..30

O

Merchant’s unique reference number

PayID

an32

M

ID assigned by Paygate for this transaction

Action

a..20

M

The parameter Action defines the type of transaction:

Credit

PayID

an32

M

ID assigned by Paygate for this transaction

Status

a..50

M

OK (URLSuccess) or FAILED (URLFailure)

Code

an8

M

Error code according to Paygate Response Codes (A4 Error codes)
