About paydirekt
General information about paydirekt
Paydirekt is a new online payment service for all German banks and savings banks and is as trustworthy as your own bank. At the heart of paydirekt is the trusted giro account through which the entire processing takes place.
The buyer registers for paydirekt via their own bank’s online system. Each payment is authorised by the buyer’s own bank and immediately posted to the giro account. Buyer authentication is via an adaptive authentication process. Each payment also requires an age verification.
The benefits for the merchant are simple connection of paydirekt to the shop system, highly secure transactions due to the processing of participating banks and savings banks and their credit rating, payment guarantee as soon as the posting is activated after positive payment confirmation and easy handling of returns and complaints
Logo |
|
Info | paydirekt allows online purchases to be paid simply and directly from your giro account. Merchants benefit from this alternative to existing online payment processes which correspond to the stringent requirements of the German credit sector. |
Type |
Further information can be found on the website of paydirekt (https://www.paydirekt.de)
Process flow chart
paydirekt process flow
Paygate interface
Definitions
Data formats
Format | Description |
a | alphabetical |
as | alphabetical with special characters |
n | numeric |
an | alphanumeric |
ans | alphanumeric with special characters |
ns | numeric with special characters |
bool | boolean expression (true or false) |
3 | fixed length with 3 digits/characters |
..3 | variable length with maximum 3 digits/characters |
enum | enumeration of allowed values |
dttm | ISODateTime (YYYY-MM-DDThh:mm:ss) |
Abbreviations
Abbreviation | Description | Comment |
CND | condition | |
M | mandatory | If a parameter is mandatory, then it must be present |
O | optional | If a parameter is optional, then it can be present, but it is not required |
C | conditional | If a parameter is conditional, then there is a conditional rule which specifies whether it is mandatory or optional |
Notice: Please note that the names of parameters can be returned in upper or lower case.
Calling the paydirekt interface
A payment by paydirekt may be done in two steps, where first of all a payment for an order is initialised before you capture it separately on dispatching the goods. Alternatively the payment can be processes within one step as a sale transaction. The subsequent transactions then take place via a server-to-server connection. Hence, you can capture these payments or issue a credit in the event of a goods return.
In order to process a payment with paydirekt via a Paygate form, please use the following URL:
https://www.computop-paygate.com/paydirekt.aspx
Notice: For security reasons, Computop Paygate rejects all payment requests with formatting errors. Therefore, please use the correct data type for each parameter.
The following table describes the encrypted payment request parameters:
| Key | REST | Format | CND | Description | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
ans..30 | M | MerchantID, assigned by Computop. Additionally this parameter has to be passed in plain language too. | ||||||||||
TransID | ans..20 | M | TransactionID which should be unique for each payment. The underscore may not be used. | |||||||||
ans..30 | O | Merchant’s unique reference number | ||||||||||
n..10 | M | Amount in the smallest currency unit (e.g. EUR Cent). Please contact the Computop Helpdesk, if you want to capture amounts <100 (smallest currency unit). | ||||||||||
a3 | M | Currency, three digits DIN / ISO 4217, e.g. EUR, USD, GBP. Please find an overview here: A1 Currency table | ||||||||||
––– | an64 | M | Hash Message Authentication Code (HMAC) with SHA-256 algorithm. Details can be found here: | |||||||||
OrderDesc | ans..768 | O | Description of purchased goods, unit prices etc. | |||||||||
ans..1024 | O | If specified at request, Paygate forwards the parameter with the payment result to the shop. | ||||||||||
ans..256 | M | Complete URL which calls up Paygate if payment has been successful. The URL may be called up only via port 443. This URL may not contain parameters: In order to exchange values between Paygate and shop, please use the parameter UserData. Common notes:
| ||||||||||
ans..256 | M | Complete URL which calls up Paygate if payment has been unsuccessful. The URL may be called up only via port 443. This URL may not contain parameters: In order to exchange values between Paygate and shop, please use the parameter UserData. Common notes:
| ||||||||||
––– | a7 | O | Status response sent by Paygate to URLSuccess and URLFailure, should be encrypted. For this purpose, transmit Response=encrypt parameter. | |||||||||
ans..256 | M | Complete URL which Paygate calls up in order to notify the shop about the payment result. The URL may be called up only via port 443. It may not contain parameters: Use the UserDataparameter instead. Common notes:
| ||||||||||
ans..32 | O | To avoid double payments or actions (e.g. by ETM), enter an alphanumeric value which identifies your transaction and may be assigned only once. If the transaction or action is submitted again with the same ReqID, Computop Paygate will not carry out the payment or new action, but will just return the status of the original transaction or action. Please note that the Computop Paygate must have a finalized transaction status for the first initial action (authentication/authorisation). This does not apply to 3-D Secure authentications that are terminated by a timeout. The 3-D Secure Timeout status does not count as a completed status in which the ReqID functionality on Paygate does not take effect. Submissions with identical ReqID for an open status will be processed regularly. Notice: Please note that a ReqID is only valid for 12 month, then it gets deleted at the Paygate. | ||||||||||
an..6 | OM | Determines the type and time of capture.
| ||||||||||
ShopApiKey | ans..64 | M | API key of the shop with paydirekt | |||||||||
shAmount | n..10 | O | Shipping costs in the smallest currency unit (e.g. EUR Cent). Please contact Computop Helpdesk, if you want to capture amounts < 100 (smallest currency unit). | |||||||||
ShoppingBasketAmount | n..10 | O | Value of ordered goods without shipping costs in the smallest currency unit (e.g. EUR Cent). Please contact Computop Helpdesk, if you want to capture amounts < 100 (smallest currency unit). | |||||||||
ArticleList | ans..1024 | O | Article list with description of items and prices: <Quantity>;<Name>;<EAN>;<Price> <;> separates the fields of an article data set <+> separates the article data sets quantity: ordered quantity of the article Name: designation of the article EAN: international article number (EAN or GTIN), (if not known, submit as empty string "”) Price: unit price of the article incl. taxes; amount in the smallest currency unit (e.g. EUR Cent) | |||||||||
ans..100 | O | Email address of the customer | ||||||||||
MinAge | n..3 | O | minimum age in years | |||||||||
ShoppingBasketCategory | ans..32 | O | Categorizes the shopping basket: „DIGITAL“ for shopping baskets with solely digital goods „PHYSICAL“ for shopping baskets with solely physical goods „MIXED“ for shopping baskets with digital and physical goods "ANONYMOUS_DONATION": The shopping basket solely is an anonymous donation "AUTHORITIES_PAYMENT": The shopping basket solely contains payments for authorities | |||||||||
sdFirstName | ans..50 | C | First name in the delivery address. Mandatory if ShoppingBasketCategory IS NOT „AUTHORITIES_PAYMENT“ and IS NOT „ANONYMOUS_DONATION“. | |||||||||
sdLastName | ans..50 | C | Surname in the delivery address. Mandatory, if ShoppingBasketCategory IS NOT „AUTHORITIES_PAYMENT“ and IS NOT „ANONYMOUS_DONATION“. | |||||||||
sdCompany | ans..100 | O | Company name in the delivery address | |||||||||
sdAddressAddition | ans..30 | O | Address addition in the delivery address | |||||||||
sdStreet | "shipping": {"addressInfo": {"addressLine1": {"street": "..." }}} | ans..100 | C | Street name in the delivery address. Mandatory, if ShoppingBasketCategory IS NOT "DIGITAL" and IS NOT "AUTHORITIES_PAYMENT" and IS NOT "ANONYMOUS_DONATION". | ||||||||
sdStreetNr | "shipping": {"addressInfo": {"addressLine1": {"streetNumber": "..." }}} | ans..8 | C | Street number in the delivery address. Mandatory, if ShoppingBasketCategory IS NOT "DIGITAL" and IS NOT "AUTHORITIES_PAYMENT" and IS NOT "ANONYMOUS_DONATION". | ||||||||
sdZip | n..5 | C | Postcode in the delivery address. Mandatory, if ShoppingBasketCategory IS NOT "DIGITAL" and IS NOT "AUTHORITIES_PAYMENT" and IS NOT "ANONYMOUS_DONATION". | |||||||||
sdCity | ans..100 | C | Town/city in the delivery address. Mandatory, if ShoppingBasketCategory IS NOT "DIGITAL" and IS NOT "AUTHORITIES_PAYMENT" and IS NOT "ANONYMOUS_DONATION". | |||||||||
sdCountryCode | an2 | C | Country code in the delivery address. Mandatory, if ShoppingBasketCategory IS NOT "DIGITAL" and IS NOT "AUTHORITIES_PAYMENT" and IS NOT "ANONYMOUS_DONATION". | |||||||||
sdEmail | ans..100 | C | Email address of the receiver. Mandatory, if ShoppingBasketCategory = „DIGITAL“. | |||||||||
Note | ans..37 | O | Text that will we displayed as reason for payment to the customer | |||||||||
CustomerID | ans..64 | O | Customer number | |||||||||
OverCapture | bool | O | Flag for overcapture checkouts. Default is false. For an overcapture checkout the sum of captures may exceed the goods value of the order up to 10%. Overcapture may be activated for checkouts of type ORDER only. OverCapture can only be used with merchants which are unlocked for this feature both at paydirekt and at Computop. | |||||||||
DeliveryMethod | ans..12 | O | Delivery place STANDARD, PACKSTATION or STORE_PICKUP. The default value is STANDARD. STANDARD: The goods will be delivered to a normal postal address. PACKSTATION: The goods will be delivered to a packstation. STORE_PICKUP: The goods will be picked-up within a branch store. For express checkouts this field always has the value STANDARD and will not be updated depending on selected delivery option. | |||||||||
DeliveryDate | dttm | O | Expected date of shipment in the format YYYY-MM-DD | |||||||||
ParcelService | ans..16 | O | Parcel service | |||||||||
TrackingNumber | ans..64 | O | Consignment number | |||||||||
ans..50 | O | A single value to be set by the merchant to return some information unencrypted in response/notify, e.g. the MID. "Plain"-parameter is part of encrypted "Data" in Computop Paygate and therefore protected against manipulation. | ||||||||||
ans..1024Format | O | "Custom"-parameter is added to the request data before encryption and is part of encrypted "Data" in Computop Paygate request. By this they are protected against manipulation by a consumer. The Custom-value is added to the Computop Paygate response in plain text and the "|" is replaced by a "&". By this you can put a single value into Custom-parameter and get multiple key-value-pairs back in response for your own purpose. Please find a sample here: Custom |
Parameters for payments with paydirekt
In case of using REST API
In case of using REST API you will always receive a link where the merchant has to redirect the consumer to complete the payment.
REST | Format | CND | Description |
"paymentId": "..." | an32 | M | May be "00000000000000000000000000000000" if not yet set by Computop Paygate |
"_Links.self.type": "..." | an..20 | M | "application/json" |
"_Links.redirect.href": "..." | an..1024 | M | Merchant needs to redirect consumer to this URL to complete payment |
"_Links.redirect.type": "..." | an..20 | M | "text/html" |
Merchant can use inquire.aspx
In case of using Key-Value-Pair API
The following table gives the result parameters which Computop Paygate transmits to URLSuccess or URLFailure and URLNotify. If you have specified the Response=encrypt parameter, the following parameters are sent Blowfish encrypted to your system:
pls. be prepared to receive additional parameters at any time and do not check the order of parameters
the key (e.g. MerchantId, RefNr) should not be checked case-sentive
| Key | Format | CND | Description |
|---|---|---|---|
ans..30 | M | MerchantID, assigned by Computop | |
an32 | M | ID assigned by Paygate for the payment, e.g. for referencing in batch files as well as for capture or credit request. | |
an32 | M | ID for all single transactions (authorisation, capture, credit note) for one payment assigned by Paygate | |
TransID | ans..20 | M | TransactionID which should be unique for each payment |
a..50 | M | OK or AUTHORIZE_REQUEST (URLSuccess) as well as FAILED (URLFailure) | |
ans..1024 | M | Further details in the event that payment is rejected. Please do not use the Description but the Code parameter for the transaction status analysis! | |
an8 | M | Error code according to Paygate Response Codes (A4 Error codes) | |
an64 | M | Hash Message Authentication Code (HMAC) with SHA-256 algorithm. Details can be found here: | |
ans..30 | O | Merchant’s unique reference number | |
ans..1024 | O | If specified at request, Paygate forwards the parameter with the payment result to the shop. | |
TID | ans..32 | O | Unique ID of this activity and all associated transactions at paydirekt. This ID exists as soon as a customer hat logged in at the checkout page. |
Reference | ans..36 | M | Unique ID of this acticity at paydirekt |
TransactionID | ans36 | O | Unique transaction-ID (UUID). The value is assigned by the paydirekt system. |
ShoppingBasketCategory | ans..32 | O | Categorizes the shopping basket: „DIGITAL“ for shopping baskets with solely digital goods „PHYSICAL“ for shopping baskets with solely physical goods „MIXED“ for shopping baskets with digital and physical goods "ANONYMOUS_DONATION": The shopping basket solely is an anonymous donation "AUTHORITIES_PAYMENT": The shopping basket solely contains payments for authorities |
sdFirstName | ans..50 | C | First name in the delivery address. Mandatory, if ShoppingBasketCategory IS NOT „AUTHORITIES_PAYMENT“ and IS NOT „ANONYMOUS_DONATION“. |
sdLastName | ans..50 | C | Surname in the delivery address. Mandatory, if ShoppingBasketCategory IS NOT „AUTHORITIES_PAYMENT“ and IS NOT „ANONYMOUS_DONATION“. |
sdCompany | ans..100 | O | Company name in the delivery address |
sdAddressAddition | ans..30 | O | Address addition in the delivery address |
sdStreet | ans..100 | C | Street name in the delivery address. Mandatory, if ShoppingBasketCategory IS NOT "DIGITAL" and IS NOT "AUTHORITIES_PAYMENT" and IS NOT "ANONYMOUS_DONATION". |
sdStreetNr | ans..8 | C | Street number in the delivery address. Mandatory, if ShoppingBasketCategory IS NOT "DIGITAL" and IS NOT "AUTHORITIES_PAYMENT" and IS NOT "ANONYMOUS_DONATION". |
sdZip | n..5 | C | Postcode in the delivery address. Mandatory, if ShoppingBasketCategory IS NOT "DIGITAL" and IS NOT "AUTHORITIES_PAYMENT" and IS NOT "ANONYMOUS_DONATION". |
sdCity | ans..100 | C | Town/city in the delivery address. Mandatory, if ShoppingBasketCategory IS NOT "DIGITAL" and IS NOT "AUTHORITIES_PAYMENT" and IS NOT "ANONYMOUS_DONATION". |
sdCountryCodey | an2 | C | Country code in the delivery address. Mandatory, if ShoppingBasketCategory IS NOT "DIGITAL" and IS NOT "AUTHORITIES_PAYMENT" and IS NOT "ANONYMOUS_DONATION". |
sdEMail | ans..100 | C | Email address of the receiver. Mandatory, if ShoppingBasketCategory = „DIGITAL“. |
AgeAccepted | a..12 | O | ACCEPTED or NOT ACCEPTED |
ans..50 | O | A single value to be set by the merchant to return some information unencrypted in response/notify, e.g. the MID. "Plain"-parameter is part of encrypted "Data" in Computop Paygate and therefore protected against manipulation. | |
ans..1024 | O | "Custom"-parameter is added to the request data before encryption and is part of encrypted "Data" in Computop Paygate request. By this they are protected against manipulation by a consumer. The Custom-value is added to the Computop Paygate response in plain text and the "|" is replaced by a "&". By this you can put a single value into Custom-parameter and get multiple key-value-pairs back in response for your own purpose. Please find a sample here: Custom |
Result parameters for URLNotify, URLSuccess and URLFailure in case of paydirekt
paydirekt oneKlick
In contrast to standard checkout the customer must register himself one-time for oneKlick. The registration is done with a separate payment (AUTHORIZE) with Paygate which cannot be used for further actions. In case of successful registration Paygate returns a token (BillingAgreementID), that can be used for all subsequent oneKlick transactions. Moreover the customer has to confirm an E-Mail before oneKlick can be used.
Optionally an URL can be submitted, to which a notify will be send, when the customer has confirmed or revoked the eMail. This URL can be stored statically in the merchant configuration or transferred via the request parameter "URLConfirm".
For an oneKlick checkout the BillingAgreementID has to be submitted to Paygate. Instead of forwarding to paydirekt now the checkout will be finished without further customer confirmation
oneKlick registration
The oneKlick registration can be done as a separate process or combined with a normal checkout. Separate registration is processed via a separate form. After the registration all subsequent transactions are made via a Server-to-Server connection. With oneKlick merchants can divide payments into authorisation and capture or can capture immediately (SALE).
Separate oneKlick registration as well as registration during checkout always is processed via the Paygate form with the following URL:
https://www.computop-paygate.com/paydirekt.aspx
Notice: DeviceID and DeviceFingerPrint must be unique for each customer's terminal device. Paydirekt offers an SDK for iOS and Android, in order to create an unique DeviceId. For web applications libraries like Fingerprint.js (https://github.com/Valve/fingerprintjs2) can be used to create an unique fingerprint.
Notice: For security reasons, Computop Paygate rejects all payment requests with formatting errors. Therefore, please use the correct data type for each parameter.
The following table describes the encrypted payment request parameters:
| Key | REST | Format | CND | Description |
|---|---|---|---|---|
ans..30 | M | MerchantID, assigned by Computop. Additionally this parameter has to be passed in plain language too. | ||
TransID | ans..20 | M | TransactionID which should be unique for each payment. The underscore may not be used. | |
ans..30 | O | Merchant’s unique reference number | ||
a3 | M | Currency, three digits DIN / ISO 4217, e.g. EUR, USD, GBP. Please find an overview here: A1 Currency table | ||
––– | an64 | M | Hash Message Authentication Code (HMAC) with SHA-256 algorithm. Details can be found here: | |
OrderDesc | ans..768 | O | Description of purchased goods, unit prices etc. | |
ans..1024 | O | If specified at request, Paygate forwards the parameter with the payment result to the shop. | ||
ans..256 | M | Complete URL which calls up Paygate if payment has been successful. The URL may be called up only via port 443. This URL may not contain parameters: In order to exchange values between Paygate and shop, please use the parameter UserData. Common notes:
| ||
ans..256 | M | Complete URL which calls up Paygate if payment has been unsuccessful. The URL may be called up only via port 443. This URL may not contain parameters: In order to exchange values between Paygate and shop, please use the parameter UserData. Common notes:
| ||
––– | a7 | O | Status response sent by Paygate to URLSuccess and URLFailure, should be encrypted. For this purpose, transmit Response=encrypt parameter. | |
ans..256 | M | Complete URL which Paygate calls up in order to notify the shop about the payment result. The URL may be called up only via port 443. It may not contain parameters: Use the UserDataparameter instead. Common notes:
| ||
URLConfirm | ans..256 | O | Complete URL which Paygate calls up when the customer has confirmed the eMail for oneKlick registration or has revoked the registration. The URL may be called up only via port 443. It may not contain parameters. | |
ans..32 | O | To avoid double payments or actions (e.g. by ETM), enter an alphanumeric value which identifies your transaction and may be assigned only once. If the transaction or action is submitted again with the same ReqID, Computop Paygate will not carry out the payment or new action, but will just return the status of the original transaction or action. Please note that the Computop Paygate must have a finalized transaction status for the first initial action (authentication/authorisation). This does not apply to 3-D Secure authentications that are terminated by a timeout. The 3-D Secure Timeout status does not count as a completed status in which the ReqID functionality on Paygate does not take effect. Submissions with identical ReqID for an open status will be processed regularly. Notice: Please note that a ReqID is only valid for 12 month, then it gets deleted at the Paygate. | ||
ShopApiKey | ans..64 | M | API key of the shop with paydirekt | |
EventToken | a8 | M | "oneKlick": Forwarding to paydirekt login page for OneKlick. "recurring": Forwarding to paydirekt login page for Recurring-OneKlick. Additionally information about payment plan can be submitted within parameter usageAgreement. Then they will be shown on the paydirect login page. "ADS" – OneKlick registration during Checkout (during Checkouts a registration for recurring is not possible). For OneKlick registration during Checkout additionally the device parameters necessary for oneKlick registration must be submitted. | |
usageAgreement | ans..256 | C | Optional, if EventToken="recurring": Details for recurring payments in JSON format. See below. | |
DeviceId | ans..64 | C | Unique Device-ID for identifying the customer’s device. Mandatory, if DeviceFingerPrint is not submitted. | |
DeviceFingerPrint | ans..64 | O | Fingerprint of the customer’s device at the time of authorisation creation | |
Device | ans..20 | M | Name of the customer’s device – will be displayed to customer within the portals. | |
ans..50 | O | A single value to be set by the merchant to return some information unencrypted in response/notify, e.g. the MID. "Plain"-parameter is part of encrypted "Data" in Computop Paygate and therefore protected against manipulation. | ||
ans..1024Format | O | "Custom"-parameter is added to the request data before encryption and is part of encrypted "Data" in Computop Paygate request. By this they are protected against manipulation by a consumer. The Custom-value is added to the Computop Paygate response in plain text and the "|" is replaced by a "&". By this you can put a single value into Custom-parameter and get multiple key-value-pairs back in response for your own purpose. Please find a sample here: Custom |
Parameters for oneKlick registration with paydirekt
usageAgreement
| Key | Format | CND | Description |
|---|---|---|---|
n..10 | M | Amount in the smallest currency unit (e.g. EUR Cent). Please contact the Computop Helpdesk, if you want to capture amounts <100 (smallest currency unit). | |
a3 | M | Currency, three digits DIN / ISO 4217, e.g. EUR, USD, GBP. Please find an overview here: A1 Currency table | |
StartDate | ans10 | M | Date of first payment within format "YYYY-MM-DD" |
IntervalUnit | a..7 | M | Payment interval ("DAY", "WEEK", "MONTH", "QUARTER", "YEAR") |
Interval | n.. | M | Frequency of payment |
Example usageAgreement as JSON string
1{2 "amount":{3 "amount":50,4 "currency":"EUR"5 },6 "startDate":"2019-09-01",7 "recurrenceInterval":{8 "intervalUnit":"WEEK",9 "interval":810 }11}The parameter created within JSON format must be Base64 encoded.
In case of using REST API
In case of using REST API you will always receive a link where the merchant has to redirect the consumer to complete the payment.
REST | Format | CND | Description |
"paymentId": "..." | an32 | M | May be "00000000000000000000000000000000" if not yet set by Computop Paygate |
"_Links.self.type": "..." | an..20 | M | "application/json" |
"_Links.redirect.href": "..." | an..1024 | M | Merchant needs to redirect consumer to this URL to complete payment |
"_Links.redirect.type": "..." | an..20 | M | "text/html" |
Merchant can use inquire.aspx
In case of using Key-Value-Pair API
The following table gives the result parameters which Computop Paygate transmits to URLSuccess or URLFailure and URLNotify. If you have specified the Response=encrypt parameter, the following parameters are sent Blowfish encrypted to your system:
pls. be prepared to receive additional parameters at any time and do not check the order of parameters
the key (e.g. MerchantId, RefNr) should not be checked case-sentive
| Key | Format | CND | Description |
|---|---|---|---|
ans..30 | M | MerchantID, assigned by Computop | |
an32 | M | ID assigned by Paygate for the payment, e.g. for referencing in batch files as well as for capture or credit request. | |
an32 | M | ID for all single transactions (authorisation, capture, credit note) for one payment assigned by Paygate | |
TransID | ans..20 | M | TransactionID which should be unique for each payment |
a..50 | M | OK or AUTHORIZE_REQUEST (URLSuccess) as well as FAILED (URLFailure) | |
ans..1024 | M | Further details in the event that payment is rejected. Please do not use the Description but the Code parameter for the transaction status analysis! | |
an8 | M | Error code according to Paygate Response Codes (A4 Error codes) | |
an64 | M | Hash Message Authentication Code (HMAC) with SHA-256 algorithm. Details can be found here: | |
ans..30 | O | Merchant’s unique reference number | |
ans..1024 | O | If specified at request, Paygate forwards the parameter with the payment result to the shop. | |
BillingAgreementID | an..44 | O | CustomerAuthorizationReference of a valid buyer authorisation. Purpose: Rights enhancement of the issued token for the opportunity to execute actions on behalf of the customer within the scope of authorisation. Is needed for oneKlick checkouts. |
ans..50 | O | A single value to be set by the merchant to return some information unencrypted in response/notify, e.g. the MID. "Plain"-parameter is part of encrypted "Data" in Computop Paygate and therefore protected against manipulation. | |
ans..1024 | O | "Custom"-parameter is added to the request data before encryption and is part of encrypted "Data" in Computop Paygate request. By this they are protected against manipulation by a consumer. The Custom-value is added to the Computop Paygate response in plain text and the "|" is replaced by a "&". By this you can put a single value into Custom-parameter and get multiple key-value-pairs back in response for your own purpose. Please find a sample here: Custom |
Result parameters for URLNotify, URLSuccess and URLFailure in case of paydirekt
The following table describes the result parameters which Paygate transmits to your URLConfirm. If you have specified the Response=encrypt parameter, the following parameters are sent Blowfish encrypted to your system:
| Key | Format | CND | Description |
|---|---|---|---|
ans..30 | M | MerchantID, assigned by Computop | |
an32 | M | ID assigned by Paygate for the payment, e.g. for referencing in batch files as well as for capture or credit request. | |
an32 | M | ID for all single transactions (authorisation, capture, credit note) for one payment assigned by Paygate | |
TransID | ans..20 | M | TransactionID which should be unique for each payment |
a..50 | M | OK (URLSuccess) or FAILED (URLFailure) | |
ans..1024 | M | Further details in the event that payment is rejected. Please do not use the Description but the Code parameter for the transaction status analysis! | |
an8 | M | Error code according to Paygate Response Codes (A4 Error codes) | |
an64 | M | Hash Message Authentication Code (HMAC) with SHA-256 algorithm. Details can be found here: | |
BillingAgreementID | an..44 | O | CustomerAuthorizationReference of a valid buyer authorisation. |
AuthorizationStatus | an..50 | APPROVED, REVOKED or EXPIRED |
Result parameters for URLConfirm in case of paydirekt
Calling the paydirekt oneKlick interface
Payments with oneKlick are possible via a server-to-server connection with help of the BillingAgreementID. Payments with oneKlick can be made as authorisation which has to be captured separately or as a sale transaction with immediate capture.
To carry out a oneKlick payment for paydirekt via a Server-to-Server connection, please use the following URL:
https://www.computop-paygate.com/oneKlick.aspx
Notice: For security reasons, Computop Paygate rejects all payment requests with formatting errors. Therefore, please use the correct data type for each parameter.
The following table describes the encrypted payment request parameters:
| Key | REST | Format | CND | Description | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
ans..30 | M | MerchantID, assigned by Computop. Additionally this parameter has to be passed in plain language too. | ||||||||||
TransID | ans..20 | M | TransactionID which should be unique for each payment. The underscore may not be used. | |||||||||
ans..30 | O | Merchant’s unique reference number | ||||||||||
n..10 | M | Amount in the smallest currency unit (e.g. EUR Cent). Please contact the Computop Helpdesk, if you want to capture amounts <100 (smallest currency unit). | ||||||||||
a3 | M | Currency, three digits DIN / ISO 4217, e.g. EUR, USD, GBP. Please find an overview here: A1 Currency table | ||||||||||
––– | an64 | M | Hash Message Authentication Code (HMAC) with SHA-256 algorithm. Details can be found here: | |||||||||
OrderDesc | ans..768 | O | Description of purchased goods, unit prices etc. | |||||||||
ans..1024 | O | If specified at request, Paygate forwards the parameter with the payment result to the shop. | ||||||||||
ans..32 | O | To avoid double payments or actions (e.g. by ETM), enter an alphanumeric value which identifies your transaction and may be assigned only once. If the transaction or action is submitted again with the same ReqID, Computop Paygate will not carry out the payment or new action, but will just return the status of the original transaction or action. Please note that the Computop Paygate must have a finalized transaction status for the first initial action (authentication/authorisation). This does not apply to 3-D Secure authentications that are terminated by a timeout. The 3-D Secure Timeout status does not count as a completed status in which the ReqID functionality on Paygate does not take effect. Submissions with identical ReqID for an open status will be processed regularly. Notice: Please note that a ReqID is only valid for 12 month, then it gets deleted at the Paygate. | ||||||||||
an..6 | OM | Determines the type and time of capture.
| ||||||||||
ShopApiKey | ans..64 | M | API key of the shop with paydirekt | |||||||||
shAmount | n..10 | O | Shipping costs in the smallest currency unit (e.g. EUR Cent). Please contact Computop Helpdesk, if you want to capture amounts < 100 (smallest currency unit). | |||||||||
ShoppingBasketAmount | n..10 | O | Value of ordered goods without shipping costs in the smallest currency unit (e.g. EUR Cent). Please contact Computop Helpdesk, if you want to capture amounts < 100 (smallest currency unit). | |||||||||
ArticleList | ans..1024 | O | Article list with description of items and prices: <Quantity>;<Name>;<EAN>;<Price> <;> separates the fields of an article data set <+> separates the article data sets quantity: ordered quantity of the article Name: designation of the article EAN: international article number (EAN or GTIN), (if not known, submit as empty string "”) Price: unit price of the article incl. taxes; amount in the smallest currency unit (e.g. EUR Cent) | |||||||||
ans..100 | O | Email address of the customer | ||||||||||
MinAge | n..3 | O | minimum age in years | |||||||||
ShoppingBasketCategory | ans..32 | O | Categorizes the shopping basket: „DIGITAL“ for shopping baskets with solely digital goods „PHYSICAL“ for shopping baskets with solely physical goods „MIXED“ for shopping baskets with digital and physical goods "ANONYMOUS_DONATION": The shopping basket solely is an anonymous donation "AUTHORITIES_PAYMENT": The shopping basket solely contains payments for authorities | |||||||||
sdFirstName | ans..50 | C | First name in the delivery address. Mandatory if ShoppingBasketCategory IS NOT „AUTHORITIES_PAYMENT“ and IS NOT „ANONYMOUS_DONATION“. | |||||||||
sdLastName | ans..50 | C | Surname in the delivery address. Mandatory, if ShoppingBasketCategory IS NOT „AUTHORITIES_PAYMENT“ and IS NOT „ANONYMOUS_DONATION“. | |||||||||
sdCompany | ans..100 | O | Company name in the delivery address | |||||||||
sdAddressAddition | ans..30 | O | Address addition in the delivery address | |||||||||
sdStreet | "shipping": {"addressInfo": {"addressLine1": {"street": "..." }}} | ans..100 | C | Street name in the delivery address. Mandatory, if ShoppingBasketCategory IS NOT "DIGITAL" and IS NOT "AUTHORITIES_PAYMENT" and IS NOT "ANONYMOUS_DONATION". | ||||||||
sdStreetNr | "shipping": {"addressInfo": {"addressLine1": {"streetNumber": "..." }}} | ans..8 | C | Street number in the delivery address. Mandatory, if ShoppingBasketCategory IS NOT "DIGITAL" and IS NOT "AUTHORITIES_PAYMENT" and IS NOT "ANONYMOUS_DONATION". | ||||||||
sdZip | n..5 | C | Postcode in the delivery address. Mandatory, if ShoppingBasketCategory IS NOT "DIGITAL" and IS NOT "AUTHORITIES_PAYMENT" and IS NOT "ANONYMOUS_DONATION". | |||||||||
sdCity | ans..100 | C | Town/city in the delivery address. Mandatory, if ShoppingBasketCategory IS NOT "DIGITAL" and IS NOT "AUTHORITIES_PAYMENT" and IS NOT "ANONYMOUS_DONATION". | |||||||||
sdCountryCode | an2 | C | Country code in the delivery address. Mandatory, if ShoppingBasketCategory IS NOT "DIGITAL" and IS NOT "AUTHORITIES_PAYMENT" and IS NOT "ANONYMOUS_DONATION". | |||||||||
sdEmail | ans..100 | C | Email address of the receiver. Mandatory, if ShoppingBasketCategory = „DIGITAL“. | |||||||||
IPAddress | ans..15 | M | Customer´s IP address | |||||||||
Note | ans..37 | O | Text that will we displayed as reason for payment to the customer | |||||||||
CustomerID | ans..64 | O | Customer number | |||||||||
DeliveryMethod | ans..12 | O | Delivery place STANDARD, PACKSTATION or STORE_PICKUP. The default value is STANDARD. STANDARD: The goods will be delivered to a normal postal address. PACKSTATION: The goods will be delivered to a packstation. STORE_PICKUP: The goods will be picked-up within a branch store. For express checkouts this field always has the value STANDARD and will not be updated depending on selected delivery option. | |||||||||
DeliveryDate | dttm | O | Expected date of shipment in the format YYYY-MM-DD | |||||||||
ParcelService | ans..16 | O | Parcel service | |||||||||
TrackingNumber | ans..64 | O | Consignment number | |||||||||
BillingAgreementID | an..44 | O | CustomerAuthorizationReference of a valid buyer authorisation. Purpose: Rights enhancement of the issued token for the opportunity to execute actions on behalf of the customer within the scope of authorisation. Is needed for oneKlick checkouts. |
Parameters for payments with paydirekt oneKlick
The following table describes the result parameters with which the Computop Paygate responds to your system
pls. be prepared to receive additional parameters at any time and do not check the order of parameters
the key (e.g. MerchantId, RefNr) should not be checked case-sentive
| Key | REST | Format | CND | Description |
|---|---|---|---|---|
ans..30 | M | MerchantID, assigned by Computop | ||
an32 | M | ID assigned by Paygate for the payment, e.g. for referencing in batch files as well as for capture or credit request. | ||
an32 | M | ID for all single transactions (authorisation, capture, credit note) for one payment assigned by Paygate | ||
TransID | ans..20 | M | TransactionID which should be unique for each payment. The underscore may not be used. | |
a..50 | M | OK or AUTHORIZE_REQUEST (URLSuccess) as well as FAILED (URLFailure) | ||
ans..1024 | M | Further details in the event that payment is rejected. Please do not use the Description but the Code parameter for the transaction status analysis! | ||
an8 | M | Error code according to Paygate Response Codes (A4 Error codes) | ||
ans..30 | O | Merchant’s unique reference number | ||
ans..1024 | O | If specified at request, Paygate forwards the parameter with the payment result to the shop. | ||
TID | ans..32 | O | Unique ID of this activity and all associated transactions at paydirekt. This ID exists as soon as a customer has logged in at the checkout page. | |
Reference | ans..36 | M | Unique ID of this acticity at paydirekt | |
TransactionID | ans36 | O | Unique transaction-ID (UUID). The value is assigned by the paydirekt system. | |
ShoppingBasketCategory | ans..32 | O | Categorizes the shopping basket: „DIGITAL“ for shopping baskets with solely digital goods „PHYSICAL“ for shopping baskets with solely physical goods „MIXED“ for shopping baskets with digital and physical goods "ANONYMOUS_DONATION": The shopping basket solely is an anonymous donation "AUTHORITIES_PAYMENT": The shopping basket solely contains payments for authorities | |
sdFirstName | ans..50 | C | First name in the delivery address. Mandatory if ShoppingBasketCategory IS NOT „AUTHORITIES_PAYMENT“ and IS NOT „ANONYMOUS_DONATION“. | |
sdLastName | ans..50 | C | Surname in the delivery address. Mandatory, if ShoppingBasketCategory IS NOT „AUTHORITIES_PAYMENT“ and IS NOT „ANONYMOUS_DONATION“. | |
sdCompany | ans..100 | O | Company name in the delivery address | |
sdAddressAddition | ans..30 | O | Address addition in the delivery address | |
sdStreet | "shipping": {"addressInfo": {"addressLine1": {"street": "..." }}} | ans..100 | C | Street name in the delivery address. Mandatory, if ShoppingBasketCategory IS NOT "DIGITAL" and IS NOT "AUTHORITIES_PAYMENT" and IS NOT "ANONYMOUS_DONATION". |
sdStreetNr | "shipping": {"addressInfo": {"addressLine1": {"streetNumber": "..." }}} | ans..8 | C | Street number in the delivery address. Mandatory, if ShoppingBasketCategory IS NOT "DIGITAL" and IS NOT "AUTHORITIES_PAYMENT" and IS NOT "ANONYMOUS_DONATION". |
sdZip | n..5 | C | Postcode in the delivery address. Mandatory, if ShoppingBasketCategory IS NOT "DIGITAL" and IS NOT "AUTHORITIES_PAYMENT" and IS NOT "ANONYMOUS_DONATION". | |
sdCity | ans..100 | C | Town/city in the delivery address. Mandatory, if ShoppingBasketCategory IS NOT "DIGITAL" and IS NOT "AUTHORITIES_PAYMENT" and IS NOT "ANONYMOUS_DONATION". | |
sdCountryCode | an2 | C | Country code in the delivery address. Mandatory, if ShoppingBasketCategory IS NOT "DIGITAL" and IS NOT "AUTHORITIES_PAYMENT" and IS NOT "ANONYMOUS_DONATION". | |
sdEmail | ans..100 | C | Email address of the receiver. Mandatory, if ShoppingBasketCategory = „DIGITAL“. | |
AgeAccepted | a..12 | O | ACCEPTED or NOT ACCEPTED |
Result parameters for URLNotify, URLSuccess and URLFailure in case of paydirekt oneKlick
Capture
Captures are possible via a Server-to-Server connection. To carry out a Capture for paydirekt via a Server-to-Server connection, please use the following URL:
https://www.computop-paygate.com/capture.aspx
Notice: For security reasons, Computop Paygate rejects all payment requests with formatting errors. Therefore, please use the correct data type for each parameter.
The following table describes the encrypted payment request parameters:
| Key | REST | Format | CND | Description |
|---|---|---|---|---|
ans..30 | M | MerchantID, assigned by Computop. Additionally this parameter has to be passed in plain language too. | ||
an32 | M | ID assigned by Paygate for the payment to be captured | ||
TransID | ans..20 | M | TransactionID which should be unique for each payment. The underscore may not be used. | |
RefNr | ns..30 | O | Merchant reference number: here a separate reference number, e.g. an invoice number, can be transferred | |
n..10 | M | Amount in the smallest currency unit (e.g. EUR Cent). Please contact the Computop Helpdesk, if you want to capture amounts <100 (smallest currency unit). | ||
a3 | M | Currency, three digits DIN / ISO 4217, e.g. EUR, USD, GBP. Please find an overview here: A1 Currency table | ||
––– | an64 | M | Hash Message Authentication Code (HMAC) with SHA-256 algorithm. Details can be found here: | |
OrderDesc | ans..768 | O | Description of purchased goods, unit prices etc. | |
ans..1024 | O | If specified at request, Paygate forwards the parameter with the payment result to the shop. | ||
ans..32 | O | To avoid double payments or actions (e.g. by ETM), enter an alphanumeric value which identifies your transaction and may be assigned only once. If the transaction or action is submitted again with the same ReqID, Computop Paygate will not carry out the payment or new action, but will just return the status of the original transaction or action. Please note that the Computop Paygate must have a finalized transaction status for the first initial action (authentication/authorisation). This does not apply to 3-D Secure authentications that are terminated by a timeout. The 3-D Secure Timeout status does not count as a completed status in which the ReqID functionality on Paygate does not take effect. Submissions with identical ReqID for an open status will be processed regularly. Notice: Please note that a ReqID is only valid for 12 month, then it gets deleted at the Paygate. | ||
CompleteType | ans..3 | O | If <YES> is transferred, the possible open order of paydirekt is closed on capture. | |
Note | ans..37 | O | Text that will we displayed as reason for payment to the customer |
Parameters for paydirekt captures
The following table describes the result parameters with which the Computop Paygate responds to your system
pls. be prepared to receive additional parameters at any time and do not check the order of parameters
the key (e.g. MerchantId, RefNr) should not be checked case-sentive
| Key | REST | Format | CND | Description |
|---|---|---|---|---|
ans..30 | M | MerchantID, assigned by Computop | ||
an32 | M | ID assigned by Paygate for the payment, e.g. for referencing in batch files as well as for capture or credit request. | ||
an32 | M | ID for all single transactions (authorisation, capture, credit note) for one payment assigned by Paygate | ||
TransID | ans..20 | M | TransactionID which should be unique for each payment. The underscore may not be used. | |
Status | a..50 | M | OK, CAPTURE_REQUEST or FAILED | |
ans..1024 | M | Further details in the event that payment is rejected. Please do not use the Description but the Code parameter for the transaction status analysis! | ||
an8 | M | Error code according to Paygate Response Codes (A4 Error codes) | ||
ans..30 | O | Merchant’s unique reference number | ||
ans..1024 | O | If specified at request, Paygate forwards the parameter with the payment result to the shop. | ||
TransactionID | ans36 | O | Unique transaction-ID of this capture (UUID). The value is assigned by the paydirekt system. |
Result parameters for paydirekt captures
Credit with reference
Credits (refunds) are possible via a Server-to-Server connection. Credits are possible up to 200% of the captured amount, if this is configured by Computop Helpdesk for the merchant and that payment method. To carry out a credit with a reference transaction, please use the following URL:
https://www.computop-paygate.com/credit.aspx
Notice: For security reasons, Computop Paygate rejects all payment requests with formatting errors. Therefore, please use the correct data type for each parameter.
The following table describes the encrypted payment request parameters:
| Key | REST | Format | CND | Description |
|---|---|---|---|---|
ans..30 | M | MerchantID, assigned by Computop. Additionally this parameter has to be passed in plain language too. | ||
an32 | M | ID assigned by Paygate for the payment to be credited | ||
TransID | ans..20 | M | TransactionID which should be unique for each payment. The underscore may not be used. | |
RefNr | ns..30 | O | Reference number (e.g. invoice number) which must be unique for each return shipment | |
n..10 | M | Amount in the smallest currency unit (e.g. EUR Cent). Please contact the Computop Helpdesk, if you want to capture amounts <100 (smallest currency unit). | ||
a3 | M | Currency, three digits DIN / ISO 4217, e.g. EUR, USD, GBP. Please find an overview here: A1 Currency table | ||
––– | an64 | M | Hash Message Authentication Code (HMAC) with SHA-256 algorithm. Details can be found here: | |
OrderDesc | ans..768 | O | Description of purchased goods, unit prices etc. | |
ans..1024 | O | If specified at request, Paygate forwards the parameter with the payment result to the shop. | ||
ans..32 | O | To avoid double payments or actions (e.g. by ETM), enter an alphanumeric value which identifies your transaction and may be assigned only once. If the transaction or action is submitted again with the same ReqID, Computop Paygate will not carry out the payment or new action, but will just return the status of the original transaction or action. Please note that the Computop Paygate must have a finalized transaction status for the first initial action (authentication/authorisation). This does not apply to 3-D Secure authentications that are terminated by a timeout. The 3-D Secure Timeout status does not count as a completed status in which the ReqID functionality on Paygate does not take effect. Submissions with identical ReqID for an open status will be processed regularly. Notice: Please note that a ReqID is only valid for 12 month, then it gets deleted at the Paygate. | ||
Note | ans..37 | O | Text that will we displayed as reason for payment to the customer |
Parameters for credits of paydirekt payments
The following table describes the result parameters with which the Computop Paygate responds to your system
pls. be prepared to receive additional parameters at any time and do not check the order of parameters
the key (e.g. MerchantId, RefNr) should not be checked case-sentive
| Key | REST | Format | CND | Description |
|---|---|---|---|---|
ans..30 | M | MerchantID, assigned by Computop | ||
an32 | M | ID assigned by Paygate for the payment, e.g. for referencing in batch files as well as for capture or credit request. | ||
an32 | M | ID for all single transactions (authorisation, capture, credit note) for one payment assigned by Paygate | ||
TransID | ans..20 | M | TransactionID which should be unique for each payment. The underscore may not be used. | |
a..50 | M | OK (URLSuccess) or FAILED (URLFailure) | ||
ans..1024 | M | Further details in the event that payment is rejected. Please do not use the Description but the Code parameter for the transaction status analysis! | ||
an8 | M | Error code according to Paygate Response Codes (A4 Error codes) | ||
ans..30 | O | Merchant’s unique reference number | ||
ans..1024 | O | If specified at request, Paygate forwards the parameter with the payment result to the shop. | ||
TransactionID | ans36 | O | Unique transaction-ID (UUID). The value is assigned by the paydirekt system. |
Result parameters for credits of paydirekt payments
Reverse
Reversals are possible via a Server-to-Server connection. In order to reverse a paydirekt transaction, please use the following URL:
https://www.computop-paygate.com/reverse.aspx
Notice: For security reasons, Computop Paygate rejects all payment requests with formatting errors. Therefore, please use the correct data type for each parameter.
The following table describes the encrypted payment request parameters:
| Key | REST | Format | CND | Description |
|---|---|---|---|---|
ans..30 | M | MerchantID, assigned by Computop. Additionally this parameter has to be passed in plain language too. | ||
an32 | M | ID assigned by Paygate for the payment to be reversed | ||
TransID | ans..20 | M | TransactionID which should be unique for each payment. The underscore may not be used. | |
n..10 | M | Amount in the smallest currency unit (e.g. EUR Cent). Please contact the Computop Helpdesk, if you want to capture amounts <100 (smallest currency unit). | ||
a3 | M | Currency, three digits DIN / ISO 4217, e.g. EUR, USD, GBP. Please find an overview here: A1 Currency table | ||
––– | an64 | M | Hash Message Authentication Code (HMAC) with SHA-256 algorithm. Details can be found here: | |
ans..32 | O | To avoid double payments or actions (e.g. by ETM), enter an alphanumeric value which identifies your transaction and may be assigned only once. If the transaction or action is submitted again with the same ReqID, Computop Paygate will not carry out the payment or new action, but will just return the status of the original transaction or action. Please note that the Computop Paygate must have a finalized transaction status for the first initial action (authentication/authorisation). This does not apply to 3-D Secure authentications that are terminated by a timeout. The 3-D Secure Timeout status does not count as a completed status in which the ReqID functionality on Paygate does not take effect. Submissions with identical ReqID for an open status will be processed regularly. Notice: Please note that a ReqID is only valid for 12 month, then it gets deleted at the Paygate. |
Parameters for reversals of paydirekt payments
The following table describes the result parameters with which the Computop Paygate responds to your system
pls. be prepared to receive additional parameters at any time and do not check the order of parameters
the key (e.g. MerchantId, RefNr) should not be checked case-sentive
| Key | REST | Format | CND | Description |
|---|---|---|---|---|
ans..30 | M | MerchantID, assigned by Computop | ||
an32 | M | ID assigned by Paygate for the payment, e.g. for referencing in batch files as well as for capture or credit request. | ||
an32 | M | ID for all single transactions (authorisation, capture, credit note) for one payment assigned by Paygate | ||
TransID | ans..20 | M | TransactionID which should be unique for each payment. The underscore may not be used. | |
n..10 | M | Amount in the smallest currency unit (e.g. EUR Cent). Please contact the Computop Helpdesk, if you want to capture amounts <100 (smallest currency unit). | ||
a3 | M | Currency, three digits DIN / ISO 4217, e.g. EUR, USD, GBP. Please find an overview here: A1 Currency table | ||
a..50 | M | OK (URLSuccess) or FAILED (URLFailure) | ||
ans..1024 | M | Further details in the event that payment is rejected. Please do not use the Description but the Code parameter for the transaction status analysis! | ||
an8 | M | Error code according to Paygate Response Codes (A4 Error codes) |
Result parameters for reversal of paydirekt payments
Batch processing via the interface
Basic information about using Batch files and about their structure can be found in the Batch Manager manual. Within batch processing not alle functions are available which are usually available for the online interface.
This section describes the parameters which must be transferred within the data set (Record) for executing a paydirekt payment and which information can be found within the response file about the payment status.
Following table gives an overview of all batch versions that are possible for a specific action and their specialities:
Action | Version | Description |
Capture | 1.0 / 2.0 | Standard version without return of parameter Code |
1.x / 2.x | with RefNr (valid for all versions other than 1.0) | |
Credit | 1.0 / 2.0 | Standard version without return of parameter Code |
1.x / 2.x | with RefNr (valid for all versions other than 1.0) |
Description of the possible batch versions
The structure for a paydirekt payment within a Batch file to be submitted is the following:
1HEAD,<MerchantID>,<Date>,<Version>2PAYDIREKT,Capture,<Amount>,<Currency>,<TransID>,(<RefNr>,)<PayID>3PAYDIREKT,Credit,<Amount>,<Currency>,<TransID>,(<RefNr>,)<PayID>4PAYDIREKT,Reverse,<Amount>,<Currency>,<TransID>,(<RefNr>,)<PayID>5FOOT,<CountRecords>,<SumAmount>Example for Master MID function:
1HEAD,[Master]MerchantID,Date,2.x2Type,Action,[Slave]MID,Amount,Currency,TransID,Data (depends on Action)3FOOT,CountRecords,SumAmountThe following table describes the individual fields and values used within the data set (record) in the batch file:
| Key | Format | CND | Description |
|---|---|---|---|
Type | a..11 | M | HEAD for Header, FOOT for Footer, PAYDIREKT for paydirekt |
Action | a..20 | M | The parameter Action defines the type of transaction: Capture Credit Reverse (cancellation) |
n..10 | M | Amount in the smallest currency unit (e.g. EUR Cent). Please contact the Computop Helpdesk, if you want to capture amounts <100 (smallest currency unit). | |
a3 | M | Currency, three digits DIN / ISO 4217, e.g. EUR, USD, GBP. Please find an overview here: A1 Currency table | |
ans..64 | M | TransactionID provided by you which should be unique for each payment | |
ans..30 | O | Merchant’s unique reference number | |
an32 | M | ID assigned by Paygate for this transaction |
Description of fields within the record for Batch files
The record area within the response file for Batch transactions looks as follows:
1HEAD,<MerchantID>,<Date>,<Version>2PAYDIREKT,Capture,<Amount>,<Currency>,<TransID>,(<RefNr>,)<PayID>,<Status>,<Code>3PAYDIREKT,Credit,<Amount>,<Currency>,<TransID>,(<RefNr>,)<PayID>,<Status>,<Code>4PAYDIREKT,Reverse,<Amount>,<Currency>,<TransID>,(<RefNr>,)<PayID>,<Status>,<Code>5FOOT,<CountRecords>,<SumAmount>The following table describes the response parameters which the Batch Manager saves in the Record area for each transaction (standard parameters not explained here, such as <TransID> or <RefNR> and request parameters are returned unchanged and correspond to the call as specified before):
| Key | Format | CND | Description |
|---|---|---|---|
Action | a..20 | M | The parameter Action defines the type of transaction: Capture Credit Reverse (cancellation) |
an32 | M | ID assigned by Paygate for this transaction | |
a..50 | M | OK (URLSuccess) or FAILED (URLFailure) | |
an8 | M | Error code according to Paygate Response Codes (A4 Error codes) |
Description of result parameters within the record for Batch files
