Info

Payments with the Brazilian credit cards Hipercard, Elo and Aura can be processed via the Paygate. Computop offers extensive support for the control optimisation as well as foreign currency conversion.

More than 30% of online payments in Brazil are made using the Boleto Bancário cash-in solution. With a payment form customers can pay in cash in supermarkets, post office branches or at one of over 48,000 bank terminals.

PIX via PagBrasil is now also supported.

Type

Payments by Credit Card

Card Scheme

VISA

MasterCard

AMEX

Diners

Elo

Aura

Hipercard

Format

Description

a

alphabetical

as

alphabetical with special characters

n

numeric

an

alphanumeric

ans

alphanumeric with special characters

ns

numeric with special characters

bool

boolean expression (true or false)

3

fixed length with 3 digits/characters

..3

variable length with maximum 3 digits/characters

enum

enumeration of allowed values

dttm

ISODateTime (YYYY-MM-DDThh:mm:ss)

Abbreviation

Description

Comment

CND

condition

M

mandatory

If a parameter is mandatory, then it must be present

O

optional

If a parameter is optional, then it can be present, but it is not required

C

conditional

If a parameter is conditional, then there is a conditional rule which specifies whether it is mandatory or optional

MerchantID

ans..30

M

MerchantID, assigned by Computop. Additionally this parameter has to be passed in plain language too.

TransID

ans..64

M

TransactionID provided by you which should be unique for each payment

refnr

ans..30

O

Merchant’s unique reference number

Amount

n..10

M

Amount in the smallest currency unit (e.g. EUR Cent). Please contact the Computop Helpdesk, if you want to capture amounts <100 (smallest currency unit).

Currency

a3

M

Currency, three digits DIN / ISO 4217, e.g. EUR, USD, GBP. Only BRL permitted. Please find an overview here: A1 Currency table

MAC

an64

M

Hash Message Authentication Code (HMAC) with SHA-256 algorithm. Details can be found here:

• HMAC Authentication (Request)

• HMAC Authentication (Notify)

URLSuccess

ans..256

M

Complete URL which calls up Paygate if payment has been successful. The URL may be called up only via port 443. This URL may not contain parameters: In order to exchange values between Paygate and shop, please use the parameter UserData.

Common notes:

• We recommend to use parameter "response=encrypt" to get an encrypted response by Paygate

• However, fraudster may just copy the encrypted DATA-element which are sent to URLFailure and send the DATA to URLSuccess/URLNotify. Therefore ensure to check the "code"-value which indicates success/failure of the action. Only a result of "code=00000000" should be considered successful.

URLFailure

ans..256

M

Complete URL which calls up Paygate if payment has been unsuccessful. The URL may be called up only via port 443. This URL may not contain parameters: In order to exchange values between Paygate and shop, please use the parameter UserData.

Common notes:

• We recommend to use parameter "response=encrypt" to get an encrypted response by Paygate

• However, fraudster may just copy the encrypted DATA-element which are sent to URLFailure and send the DATA to URLSuccess/URLNotify. Therefore ensure to check the "code"-value which indicates success/failure of the action. Only a result of "code=00000000" should be considered successful.

Response

a7

O

Status response sent by Paygate to URLSuccess and URLFailure, should be encrypted. For this purpose, transmit Response=encrypt parameter.

URLNotify

ans..256

M

Complete URL which Paygate calls up in order to notify the shop about the payment result. The URL may be called up only via port 443. It may not contain parameters: Use the UserDataparameter instead.

Common notes:

• Before follow-up actions (capture / credit / reversal) are carried out on an existing transaction, the first Notify must have been answered by the shop.

• Fraudster may just copy the encrypted DATA-element which are sent to URLFailure and send the DATA to URLSuccess/URLNotify. Therefore ensure to check the "code"-value which indicates success/failure of the action. Only a result of "code=00000000" should be considered successful.

UserData

ans..1024

O

If specified at request, Paygate forwards the parameter with the payment result to the shop.

ReqId

ans..32

O

To avoid double payments or actions (e.g. by ETM), enter an alphanumeric value which identifies your transaction and may be assigned only once. If the transaction or action is submitted again with the same ReqID, Computop Paygate will not carry out the payment or new action, but will just return the status of the original transaction or action.

Please note that the Computop Paygate must have a finalized transaction status for the first initial action (authentication/authorisation). This does not apply to 3-D Secure authentications that are terminated by a timeout. The 3-D Secure Timeout status does not count as a completed status in which the ReqID functionality on Paygate does not take effect. Submissions with identical ReqID for an open status will be processed regularly.

Notice: Please note that a ReqID is only valid for 12 month, then it gets deleted at the Paygate.

Capture

an..6

OM

Determines the type and time of capture.

CreditCardHolder

ans..60

M

Name of the card holder

Name

ans..128

O

Name of the customer. If Name is not specified, the CreditCardHolder is transferred.

AddrStreet

ans..46

M

Customer's street name (Optional, if agreed with PagBrasil and Computop)

AddrCity

ans..40

M

Customer's town/city (Optional, if agreed with PagBrasil and Computop)

AddrZip

ans..8

M

Customer's post code (Optional, if agreed with PagBrasil and Computop)

AddrState

a2

M

Abbreviation of the customer’s Federal State. See the following table for the Federal States of Brazil. (Optional, if agreed with PagBrasil and Computop)

TaxNumber

n11/n14

M

In Brazil there are two kinds of tax numbers:

CPF for persons and CNPJ for companies.

CPF: 11 characters without separators, e.g. 12312312312

CNPJ: 14 characters without separators, e.g. 12345678000123

eMail

ans..128

M

Customer's email address (Optional, if agreed with PagBrasil and Computop)

Phone

ans..40

M

Customer's phone number (Optional, if agreed with PagBrasil and Computop)

ChDesc

ans..12

M

Text printed on the customer’s credit card bill alongside the payee (‘PAGBRASIL’)

OrderDesc

ans..768

M

Description of purchased goods, unit prices etc.

ArticleList

ans..254

O

Description of the goods purchased.

Example: ProductName; Quantity+ProductName;Number

The product and the quantity are indicated on the customer’s bill.

InstallmentNumber

n..2

O

Number of months of the payment by instalments (1-12), default=1.

Plain

ans..50

O

A single value to be set by the merchant to return some information unencrypted in response/notify, e.g. the MID.

"Plain"-parameter is part of encrypted "Data" in Computop Paygate and therefore protected against manipulation.

Custom

ans..1024

O

"Custom"-parameter is added to the request data before encryption and is part of encrypted "Data" in Computop Paygate request. By this they are protected against manipulation by a consumer.

The Custom-value is added to the Computop Paygate response in plain text and the "|" is replaced by a "&". By this you can put a single value into Custom-parameter and get multiple key-value-pairs back in response for your own purpose.

Please find a sample here: Custom

IPAddr

ans..45

O

Cardholder‘s IP address (v4 or v6)

DeviceID

ans..128

O

Cardholder‘s DeviceID for operation

Template

ans..20

O

Name of XSLT-file with your own layout for the pay form. If you want to use the redesigned and downwards compatible Computop template, please transfer the template name “ct_compatible”. If you want to use the responsive Computop template for mobile devices, please transfer the template name “ct_responsive”.

Background

ans..256

O

Background ambiance of form:

URL for a background image

- HTML-colour value for background colour as HEX value or

- HTML-colour name

BGColor

ans..7

O

Form background colour:

- HTML-colour value for background colour as HEX value or

- HTML-colour name

BGImage

ans..256

O

Form background image:

URL for a background image

Please note that this value supersedes “BGColor”.

FColor

ans..7

O

Text colour:

- HTML-colour value as HEX value or

- HTML-colour name

FFace

a..10

O

HTML-name for the font

FSize

n2

O

Number for font size

Language

a2

O

Language code: <de> German, <al> Albanian, <at> Austrian, <cz/cs> Czech, <dk> Danish, <en> English, <fi> Finish, <fr> French, <gr> Greek, <hu> Hungarian, <it> Italian, <jp> Japanese,  <nl> Dutch, <no> Norwegian, <pl> Polish, <pt> Portuguese, <ro> Romanian, <ru> Russian, <es> Spanish, <se> Swedish, <sk> Slovakian, <sl> Slovenian, <tr> Turkey, <zh> Simplified Chinese.

CCSelect

a..16

O

Determines preselected card type in the form: VISA, MasterCard, AMEX, DINERS, JCB, CBN, Hipercard, Elo, Aura, Dankort, Airplus, ComfortCard, CUP or Maestro

URLBack

ans..256

O

Complete URL which Paygate calls in case that Cancel is clicked by the customer.

The parameter "URLBack" can be sent

• either as plain parameter (unencrypted) (compatibility mode)

• or be part of encrypted payment request parameters (preferred mode)

In order to exchange values between Paygate and shop you may use something like this:

URLBack=https://your.shop.com/back.php?param1%3Dvalue1%26param2%3Dvalue3%26status%3Dcancelled

When user cancels payment this URL is called exactly like this and you may use URL Decode to extract parameter and values.

Center

n1

O

By default the form is centered vertically and horizontally. The value <1> centres the form at the top.

tWidth

ans..4

O

Width of table for input in the form as percent- (50%) or pixel values (320).

tHeight

ans..4

O

Height of table for input of the payment data in the form as percent- (70%) or pixel values (480).

CustomField[n]

ans..50

O

Merchants can customize up to 14 special fields (called CustomField1 to CustomField14) on their payment form template. CustomFields are a feature that allows you to show additional information such as your logo, order details and customer details on the payment form.

Special characters (like &, ', <, >) are not allowed – even not "urlencoded".

The usage / display of CustomField{n] depends on the template that is used.

mid

ans..30

M

MerchantID, assigned by Computop

PayID

an32

M

ID assigned by Paygate for the payment, e.g. for referencing in batch files as well as for capture or credit request.

XID

an32

M

ID for all single transactions (authorisation, capture, credit note) for one payment assigned by Paygate

TransID

ans..64

M

TransactionID provided by you which should be unique for each payment

refnr

ans..30

O

Merchant’s unique reference number

OrderID

ans15

MC

Not to URLNotify: Corresponds to RefNr or TransID, depending on whether RefNr is transmitted or not.

Status

a..50

M

OK or AUTHORIZE_REQUEST (URLSuccess) as well as FAILED (URLFailure)

OK or FAILED on URLNotify

Description

ans..1024

M

Further details in the event that payment is rejected. Please do not use the Description but the Code parameter for the transaction status analysis!

Code

an8

M

Error code according to Paygate Response Codes (A4 Error codes)

MAC

an64

M

Hash Message Authentication Code (HMAC) with SHA-256 algorithm. Details can be found here:

• HMAC Authentication (Request)

• HMAC Authentication (Notify)

UserData

ans..1024

O

If specified at request, Paygate forwards the parameter with the payment result to the shop.

PCNr

n16

O

Pseudo Card Number: Random number generated by Computop Paygate which represents a genuine credit card number. The pseudo card number (PCN) starts with 0 and the last 3 digits correspond to those of the real card number. The PCN can be used like a genuine card number for authorisation, capture and credits.

PCNr is a response value from Computop Paygate and is sent as CCNr in Request or part of card-JSON

CCBrand

a..22

O

In combination with PCNr: Description of the credit card brand including VISA, MasterCard, AMEX, DINERS, Elo, Aura or Hipercard

CCExpiry

n6

O

In combination with PCNr: Expiry date of the credit card in the format YYYYMM

MaskedCCNr

an..19

OC

Masked card number 6X4

Plain

ans..50

O

A single value to be set by the merchant to return some information unencrypted in response/notify, e.g. the MID.

"Plain"-parameter is part of encrypted "Data" in Computop Paygate and therefore protected against manipulation.

Custom

ans..1024

O

"Custom"-parameter is added to the request data before encryption and is part of encrypted "Data" in Computop Paygate request. By this they are protected against manipulation by a consumer.

The Custom-value is added to the Computop Paygate response in plain text and the "|" is replaced by a "&". By this you can put a single value into Custom-parameter and get multiple key-value-pairs back in response for your own purpose.

Please find a sample here: Custom

Federal State

Abbreviation

Acre

AC

Alagoas

AL

Amapá

AP

Amazonas

AM

Bahia

BA

Ceará

CE

Distrito Federal

DF

Espírito Santo

ES

Goias

GO

Maranhão

MA

Mato Grosso

MT

Mato Grosso do Sul

MS

Minas Gerais

MG

Pará

PA

Paraíba

PB

Paraná

PR

Pernambuco

PE

Piauí

PI

Rio de Janeiro

RJ

Rio Grande do Norte

RN

Rio Grande do Sul

RS

Rondônia

RO

Roraima

RR

Santa Catarina

SC

São Paulo

SP

Sergipe

SE

Tocantins

TO

MerchantID

ans..30

M

MerchantID, assigned by Computop. Additionally this parameter has to be passed in plain language too.

TransID

ans..64

M

TransactionID provided by you which should be unique for each payment

refnr

ans..30

O

Merchant’s unique reference number

Amount

n..10

M

Amount in the smallest currency unit (e.g. EUR Cent). Please contact the Computop Helpdesk, if you want to capture amounts <100 (smallest currency unit).

Currency

a3

M

Currency, three digits DIN / ISO 4217, e.g. EUR, USD, GBP. Only BRL permitted. Please find an overview here: A1 Currency table

MAC

an64

M

Hash Message Authentication Code (HMAC) with SHA-256 algorithm. Details can be found here:

• HMAC Authentication (Request)

• HMAC Authentication (Notify)

URLNotify

ans..256

O

Complete URL which Paygate calls up in order to notify the shop about the payment result. The URL may be called up only via port 443. It may not contain parameters: Use the UserData parameter instead.

The URL is called only if it is a payment with Hipercard, since in this case the reply from the acquirer is sent with a time delay. Alternatively the payment status can be queried via inquire.aspx.

Common notes:

• We recommend to use parameter "response=encrypt" to get an encrypted response by Paygate

• However, fraudster may just copy the encrypted DATA-element which are sent to URLFailure and send the DATA to URLSuccess/URLNotify. Therefore ensure to check the "code"-value which indicates success/failure of the action. Only a result of "code=00000000" should be considered successful.

UserData

ans..1024

O

If specified at request, Paygate forwards the parameter with the payment result to the shop.

ReqId

ans..32

O

To avoid double payments or actions (e.g. by ETM), enter an alphanumeric value which identifies your transaction and may be assigned only once. If the transaction or action is submitted again with the same ReqID, Computop Paygate will not carry out the payment or new action, but will just return the status of the original transaction or action.

Please note that the Computop Paygate must have a finalized transaction status for the first initial action (authentication/authorisation). This does not apply to 3-D Secure authentications that are terminated by a timeout. The 3-D Secure Timeout status does not count as a completed status in which the ReqID functionality on Paygate does not take effect. Submissions with identical ReqID for an open status will be processed regularly.

Notice: Please note that a ReqID is only valid for 12 month, then it gets deleted at the Paygate.

Capture

an..6

OM

Determines the type and time of capture.

CCNr

n..19

M

Credit card number at least 12-digit, numerical without spaces. You can optionally transmit also a pseudo card number (PCN)

CCCVC

n..4

O

Card verification number: The last 3 digits on the signature strip of the credit card. 4 characters in the case of AMEX.

CCExpiry

n6

M

Credit card expiry date (YYYYMM), e.g. 202607

CCBrand

a..22

M

Card type: VISA, MasterCard, AMEX, DINERS, Elo, Aura or Hipercard. Please note the spelling!

CreditCardHolder

ans..60

M

Name of the card holder

Name

ans..128

O

Name of the customer. If Name is not specified, the CreditCardHolder is transferred.

AddrStreet

ans..46

M

Customer's street name (Optional, if agreed with PagBrasil and Computop)

AddrCity

ans..40

M

Customer's town/city (Optional, if agreed with PagBrasil and Computop)

AddrZip

ans..8

M

Customer's post code (Optional, if agreed with PagBrasil and Computop)

AddrState

a2

M

Abbreviation of the customer’s Federal State. See the following table for the Federal States of Brazil. (Optional, if agreed with PagBrasil and Computop)

TaxNumber

n11/n14

M

In Brazil there are two kinds of tax numbers:

CPF for persons and CNPJ for companies.

CPF: 11 characters without separators, e.g. 12312312312

CNPJ: 14 characters without separators, e.g. 12345678000123

eMail

ans..128

M

Customer's email address (Optional, if agreed with PagBrasil and Computop)

Phone

ans..40

M

Customer's phone number (Optional, if agreed with PagBrasil and Computop)

ChDesc

ans..12

M

Text printed on the customer’s credit card bill alongside the payee (‘PAGBRASIL’)

OrderDesc

ans..768

M

Description of purchased goods, unit prices etc.

ArticleList

ans..254

O

Description of the goods purchased.

Example: ProductName; Quantity+ProductName;Number

The product and the quantity are indicated on the customer’s bill.

InstallmentNumber

n..2

O

Number of months of the payment by instalments (1-12), default=1.

IPAddr

ans..45

O

Cardholder‘s IP address (v4 or v6)

DeviceID

ans..128

O

Cardholder‘s DeviceID for operation

mid

ans..30

M

MerchantID, assigned by Computop

PayID

an32

M

ID assigned by Paygate for the payment, e.g. for referencing in batch files as well as for capture or credit request.

XID

an32

M

ID for all single transactions (authorisation, capture, credit note) for one payment assigned by Paygate

TransID

ans..64

M

TransactionID provided by you which should be unique for each payment

refnr

ans..30

O

Merchant’s unique reference number

OrderID

ans15

M

Corresponds to RefNr or TransID, depending on whether RefNr is transmitted or not.

Status

a..50

M

OK (URLSuccess) or FAILED (URLFailure)

Description

ans..1024

M

Further details in the event that payment is rejected. Please do not use the Description but the Code parameter for the transaction status analysis!

Code

an8

M

Error code according to Paygate Response Codes (A4 Error codes)

UserData

ans..1024

O

If specified at request, Paygate forwards the parameter with the payment result to the shop.

PCNr

n16

O

Pseudo Card Number: Random number generated by Computop Paygate which represents a genuine credit card number. The pseudo card number (PCN) starts with 0 and the last 3 digits correspond to those of the real card number. The PCN can be used like a genuine card number for authorisation, capture and credits.

PCNr is a response value from Computop Paygate and is sent as CCNr in Request or part of card-JSON

CCBrand

a..22

M

Card type: VISA, MasterCard, AMEX, DINERS, Elo, Aura or Hipercard. Please note the spelling!

CCExpiry

n6

M

Credit card expiry date (YYYYMM), e.g. 202607

MaskedCCNr

an..19

OC

Masked card number 6X4

acsURL

string

C

Merchant receives acsURL and needs to redirect customer to this URL to complete authentication

mid

ans..30

M

MerchantID, assigned by Computop

PayID

an32

M

ID assigned by Paygate for the payment, e.g. for referencing in batch files as well as for capture or credit request.

XID

an32

M

ID for all single transactions (authorisation, capture, credit note) for one payment assigned by Paygate

TransID

ans..64

M

TransactionID provided by you which should be unique for each payment

refnr

ans..30

O

Merchant’s unique reference number

Status

a..50

M

OK (URLSuccess) or FAILED (URLFailure)

Description

ans..1024

M

Further details in the event that payment is rejected. Please do not use the Description but the Code parameter for the transaction status analysis!

Code

an8

M

Error code according to Paygate Response Codes (A4 Error codes)

UserData

ans..1024

O

If specified at request, Paygate forwards the parameter with the payment result to the shop.

MerchantID

ans..30

M

MerchantID, assigned by Computop. Additionally this parameter has to be passed in plain language too.

TransID

ans..64

M

TransactionID provided by you which should be unique for each payment

refnr

ans..30

O

Merchant’s unique reference number

Amount

n..10

M

Amount in the smallest currency unit (e.g. EUR Cent). Please contact the Computop Helpdesk, if you want to capture amounts <100 (smallest currency unit).

Currency

a3

M

Currency, three digits DIN / ISO 4217, e.g. EUR, USD, GBP. Only BRL permitted. Please find an overview here: A1 Currency table

MAC

an64

M

Hash Message Authentication Code (HMAC) with SHA-256 algorithm. Details can be found here:

• HMAC Authentication (Request)

• HMAC Authentication (Notify)

URLSuccess

ans..256

M

Complete URL which calls up Paygate if payment has been successful. The URL may be called up only via port 443. This URL may not contain parameters: In order to exchange values between Paygate and shop, please use the parameter UserData.

Common notes:

• We recommend to use parameter "response=encrypt" to get an encrypted response by Paygate

• However, fraudster may just copy the encrypted DATA-element which are sent to URLFailure and send the DATA to URLSuccess/URLNotify. Therefore ensure to check the "code"-value which indicates success/failure of the action. Only a result of "code=00000000" should be considered successful.

URLFailure

ans..256

M

Complete URL which calls up Paygate if payment has been unsuccessful. The URL may be called up only via port 443. This URL may not contain parameters: In order to exchange values between Paygate and shop, please use the parameter UserData.

Common notes:

• We recommend to use parameter "response=encrypt" to get an encrypted response by Paygate

• However, fraudster may just copy the encrypted DATA-element which are sent to URLFailure and send the DATA to URLSuccess/URLNotify. Therefore ensure to check the "code"-value which indicates success/failure of the action. Only a result of "code=00000000" should be considered successful.

Response

a7

O

Status response sent by Paygate to URLSuccess and URLFailure, should be encrypted. For this purpose, transmit Response=encrypt parameter.

URLNotify

ans..256

M

Complete URL which Paygate calls up in order to notify the shop about the payment result. The URL may be called up only via port 443. It may not contain parameters: Use the UserDataparameter instead.

Common notes:

• Before follow-up actions (capture / credit / reversal) are carried out on an existing transaction, the first Notify must have been answered by the shop.

• Fraudster may just copy the encrypted DATA-element which are sent to URLFailure and send the DATA to URLSuccess/URLNotify. Therefore ensure to check the "code"-value which indicates success/failure of the action. Only a result of "code=00000000" should be considered successful.

UserData

ans..1024

O

If specified at request, Paygate forwards the parameter with the payment result to the shop.

ReqId

ans..32

O

To avoid double payments or actions (e.g. by ETM), enter an alphanumeric value which identifies your transaction and may be assigned only once. If the transaction or action is submitted again with the same ReqID, Computop Paygate will not carry out the payment or new action, but will just return the status of the original transaction or action.

Please note that the Computop Paygate must have a finalized transaction status for the first initial action (authentication/authorisation). This does not apply to 3-D Secure authentications that are terminated by a timeout. The 3-D Secure Timeout status does not count as a completed status in which the ReqID functionality on Paygate does not take effect. Submissions with identical ReqID for an open status will be processed regularly.

Notice: Please note that a ReqID is only valid for 12 month, then it gets deleted at the Paygate.

Name

ans..128

O

Name of the customer

AddrStreet

ans..46

M

Customer's street name (Optional, if agreed with PagBrasil and Computop, but not for BankCode = U)

AddrCity

ans..40

M

Customer's town/city (Optional, if agreed with PagBrasil and Computop, but not for BankCode = U)

AddrZip

ans..8

M

Customer's post code (Optional, if agreed with PagBrasil and Computop, but not for BankCode = U)

AddrState

a2

M

Abbreviation of the customer’s Federal State. See the table above for the Federal States of Brazil. (Optional, if agreed with PagBrasil and Computop, but not for BankCode = U)

TaxNumber

n11/n14

M

In Brazil there are two kinds of tax numbers:

CPF for persons and CNPJ for companies.

CPF: 11 characters without separators, e.g. 12312312312

CNPJ: 14 characters without separators, e.g. 12345678000123

eMail

ans..128

M

Customer's email address (Optional, if agreed with PagBrasil and Computop, but not for BankCode = U)

Phone

ans..40

M

Customer's phone number (Optional, if agreed with PagBrasil and Computop, but not for BankCode = U)

OrderDesc

ans..768

M

Description of purchased goods, unit prices etc.

ArticleList

ans..254

O

Description of the goods purchased.

Example: ProductName; Quantity+ProductName;Number

The product and the quantity are indicated on the customer’s bill.

BankCode

enum

M

Identification of the financial institution of the customer

R = Bradesco Comércio Eletrônico

E = Banco do Brasil Comércio Eletrônico

S = Banricompras

U = Itaú Shopline

Plain

ans..50

O

A single value to be set by the merchant to return some information unencrypted in response/notify, e.g. the MID.

"Plain"-parameter is part of encrypted "Data" in Computop Paygate and therefore protected against manipulation.

Custom

ans..1024

O

"Custom"-parameter is added to the request data before encryption and is part of encrypted "Data" in Computop Paygate request. By this they are protected against manipulation by a consumer.

The Custom-value is added to the Computop Paygate response in plain text and the "|" is replaced by a "&". By this you can put a single value into Custom-parameter and get multiple key-value-pairs back in response for your own purpose.

Please find a sample here: Custom

mid

ans..30

M

MerchantID, assigned by Computop

PayID

an32

M

ID assigned by Paygate for the payment, e.g. for referencing in batch files as well as for capture or credit request.

XID

an32

M

ID for all single transactions (authorisation, capture, credit note) for one payment assigned by Paygate

TransID

ans..64

M

TransactionID provided by you which should be unique for each payment

refnr

ans..30

O

Merchant’s unique reference number

OrderID

ans15

MC

Not to URLNotify: Corresponds to RefNr or TransID, depending on whether RefNr is transmitted or not.

Status

a..50

M

OK (URLSuccess) or FAILED (URLFailure)

Description

ans..1024

M

Further details in the event that payment is rejected. Please do not use the Description but the Code parameter for the transaction status analysis!

Code

an8

M

Error code according to Paygate Response Codes (A4 Error codes)

MAC

an64

M

Hash Message Authentication Code (HMAC) with SHA-256 algorithm. Details can be found here:

• HMAC Authentication (Request)

• HMAC Authentication (Notify)

UserData

ans..1024

O

If specified at request, Paygate forwards the parameter with the payment result to the shop.

Plain

ans..50

O

A single value to be set by the merchant to return some information unencrypted in response/notify, e.g. the MID.

"Plain"-parameter is part of encrypted "Data" in Computop Paygate and therefore protected against manipulation.

Custom

ans..1024

O

"Custom"-parameter is added to the request data before encryption and is part of encrypted "Data" in Computop Paygate request. By this they are protected against manipulation by a consumer.

The Custom-value is added to the Computop Paygate response in plain text and the "|" is replaced by a "&". By this you can put a single value into Custom-parameter and get multiple key-value-pairs back in response for your own purpose.

Please find a sample here: Custom

MerchantID

ans..30

M

MerchantID, assigned by Computop. Additionally this parameter has to be passed in plain language too.

TransID

ans..64

M

TransactionID provided by you which should be unique for each payment

RefNr

ans..30

M

Unique reference number. Format must be mutually agreed beforehand with Computop!

Amount

n..10

M

Amount in the smallest currency unit (e.g. EUR Cent). Please contact the Computop Helpdesk, if you want to capture amounts <100 (smallest currency unit).

Currency

a3

M

Currency, three digits DIN / ISO 4217, e.g. EUR, USD, GBP. Only BRL permitted. Please find an overview here: A1 Currency table

MAC

an64

M

Hash Message Authentication Code (HMAC) with SHA-256 algorithm. Details can be found here:

• HMAC Authentication (Request)

• HMAC Authentication (Notify)

UserData

ans..1024

O

If specified at request, Paygate forwards the parameter with the payment result to the shop.

URLNotify

ans..256

M

Complete URL which Paygate calls up in order to notify the shop about the payment result. The URL may be called up only via port 443. It may not contain parameters: Use the UserDataparameter instead.

Common notes:

• Before follow-up actions (capture / credit / reversal) are carried out on an existing transaction, the first Notify must have been answered by the shop.

• Fraudster may just copy the encrypted DATA-element which are sent to URLFailure and send the DATA to URLSuccess/URLNotify. Therefore ensure to check the "code"-value which indicates success/failure of the action. Only a result of "code=00000000" should be considered successful.

Name

ans..128

M

Name of the customer

AddrStreet

ans..46

M

Customer's street name (Optional, if agreed with PagBrasil and Computop)

AddrCity

ans..40

M

Customer's town/city (Optional, if agreed with PagBrasil and Computop)

AddrZip

ans..8

M

Customer's post code (Optional, if agreed with PagBrasil and Computop)

AddrState

a2

M

Abbreviation of the customer’s Federal State. See the following table for the Federal States of Brazil. (Optional, if agreed with PagBrasil and Computop)

TaxNumber

n11/n14

M

In Brazil there are two kinds of tax numbers:

CPF for persons and CNPJ for companies.

CPF: 11 characters without separators, e.g. 12312312312

CNPJ: 14 characters without separators, e.g. 12345678000123

eMail

ans..128

M

Customer's email address (Optional, if agreed with PagBrasil and Computop)

Phone

ans..40

M

Customer's phone number (Optional, if agreed with PagBrasil and Computop)

OrderDesc

ans..768

M

Description of purchased goods, unit prices etc.

ArticleList

ans..254

M

Description of the goods purchased.

Example: ProductName; Quantity+ProductName;Number

The product and the quantity are indicated on the customer’s bill.

Expiration

n..4

O

Number of days the payment form is valid

Custom

ans..1024

O

"Custom"-parameter is added to the request data before encryption and is part of encrypted "Data" in Computop Paygate request. By this they are protected against manipulation by a consumer.

The Custom-value is added to the Computop Paygate response in plain text and the "|" is replaced by a "&". By this you can put a single value into Custom-parameter and get multiple key-value-pairs back in response for your own purpose.

Please find a sample here: Custom

mid

ans..30

M

MerchantID, assigned by Computop

PayID

an32

M

ID assigned by Paygate for the payment, e.g. for referencing in batch files as well as for capture or credit request.

XID

an32

M

ID for all single transactions (authorisation, capture, credit note) for one payment assigned by Paygate

TransID

ans..64

M

TransactionID provided by you which should be unique for each payment

refnr

ans..30

O

Merchant’s unique reference number

OrderID

ans15

MC

Not to URLNotify: Corresponds to RefNr or TransID, depending on whether RefNr is transmitted or not.

Status

a..50

M

OK (URLSuccess) or FAILED (URLFailure)

Description

ans..1024

M

Further details in the event that payment is rejected. Please do not use the Description but the Code parameter for the transaction status analysis!

Code

an8

M

Error code according to Paygate Response Codes (A4 Error codes)

UserData

ans..1024

O

If specified at request, Paygate forwards the parameter with the payment result to the shop.

PaymentSlipLink

ans..256

M

Complete URL (URL-encoded) for the page which presents the payment form

mid

ans..30

M

MerchantID, assigned by Computop

PayID

an32

M

ID assigned by Paygate for the payment, e.g. for referencing in batch files as well as for capture or credit request.

XID

an32

M

ID for all single transactions (authorisation, capture, credit note) for one payment assigned by Paygate

TransID

ans..64

M

TransactionID provided by you which should be unique for each payment

refnr

ans..30

O

Merchant’s unique reference number

Status

a..50

M

OK (URLSuccess) or FAILED (URLFailure)

Description

ans..1024

M

Further details in the event that payment is rejected. Please do not use the Description but the Code parameter for the transaction status analysis!

Code

an8

M

Error code according to Paygate Response Codes (A4 Error codes)

UserData

ans..1024

O

If specified at request, Paygate forwards the parameter with the payment result to the shop.

PaymentSlipLink

ans..256

M

Complete URL (URL-encoded) for the page which presents the payment form

AmountAuth

n..10

M

Authorized amount in the smallest currency unit (e.g. BRL Centavos)

AmountCap

n..10

M

Captured amount in the smallest currency unit (e.g. BRL Centavos). Used to check whether the total amount has been captured.

AmountCred

n..10

M

Credited amount in the smallest currency unit (e.g. BRL Centavos)

PaymentDate

dttm

M

Date when the Boleto Bancário was paid by the customer. Format: YYYY-MM-DD.

Custom

ans..1024

O

"Custom"-parameter is added to the request data before encryption and is part of encrypted "Data" in Computop Paygate request. By this they are protected against manipulation by a consumer.

The Custom-value is added to the Computop Paygate response in plain text and the "|" is replaced by a "&". By this you can put a single value into Custom-parameter and get multiple key-value-pairs back in response for your own purpose.

Please find a sample here: Custom

MerchantID

ans..30

M

MerchantID, assigned by Computop. Additionally this parameter has to be passed in plain language too.

TransID

ans..64

M

TransactionID provided by you which should be unique for each payment

RefNr

ans..30

M

Unique reference number. Format must be mutually agreed beforehand with Computop!

Amount

n..10

M

Amount in the smallest currency unit (e.g. EUR Cent). Please contact the Computop Helpdesk, if you want to capture amounts <100 (smallest currency unit).

Currency

a3

M

Currency, three digits DIN / ISO 4217, e.g. EUR, USD, GBP. Only BRL permitted. Please find an overview here: A1 Currency table

MAC

an64

M

Hash Message Authentication Code (HMAC) with SHA-256 algorithm. Details can be found here:

• HMAC Authentication (Request)

• HMAC Authentication (Notify)

UserData

ans..1024

O

If specified at request, Paygate forwards the parameter with the payment result to the shop.

URLNotify

ans..256

M

Complete URL which Paygate calls up in order to notify the shop about the payment result. The URL may be called up only via port 443. It may not contain parameters: Use the UserDataparameter instead.

Common notes:

• Before follow-up actions (capture / credit / reversal) are carried out on an existing transaction, the first Notify must have been answered by the shop.

• Fraudster may just copy the encrypted DATA-element which are sent to URLFailure and send the DATA to URLSuccess/URLNotify. Therefore ensure to check the "code"-value which indicates success/failure of the action. Only a result of "code=00000000" should be considered successful.

Name

ans..128

M

Name of the customer

AddrStreet

ans..46

M

Customer's street name (Optional, if agreed with PagBrasil and Computop)

AddrCity

ans..40

M

Customer's town/city (Optional, if agreed with PagBrasil and Computop)

AddrZip

ans..8

M

Customer's post code (Optional, if agreed with PagBrasil and Computop)

AddrState

a2

M

Abbreviation of the customer’s Federal State. See the following table for the Federal States of Brazil. (Optional, if agreed with PagBrasil and Computop)

TaxNumber

n11/n14

M

In Brazil there are two kinds of tax numbers:

CPF for persons and CNPJ for companies.

CPF: 11 characters without separators, e.g. 12312312312

CNPJ: 14 characters without separators, e.g. 12345678000123

eMail

ans..128

M

Customer's email address (Optional, if agreed with PagBrasil and Computop)

Phone

ans..40

M

Customer's phone number (Optional, if agreed with PagBrasil and Computop)

OrderDesc

ans..768

M

Description of purchased goods, unit prices etc.

ArticleList

ans..254

M

Description of the goods purchased.

Example: ProductName; Quantity+ProductName;Number

The product and the quantity are indicated on the customer’s bill.

Expiration

n..4

O

Number of minutes for which the payment form is valid. the value can be from 1 to 7200.

Custom

ans..1024

O

"Custom"-parameter is added to the request data before encryption and is part of encrypted "Data" in Computop Paygate request. By this they are protected against manipulation by a consumer.

The Custom-value is added to the Computop Paygate response in plain text and the "|" is replaced by a "&". By this you can put a single value into Custom-parameter and get multiple key-value-pairs back in response for your own purpose.

Please find a sample here: Custom

mid

ans..30

M

MerchantID, assigned by Computop

PayID

an32

M

ID assigned by Paygate for the payment, e.g. for referencing in batch files as well as for capture or credit request.

XID

an32

M

ID for all single transactions (authorisation, capture, credit note) for one payment assigned by Paygate

TransID

ans..64

M

TransactionID provided by you which should be unique for each payment

refnr

ans..30

O

Merchant’s unique reference number

OrderID

ans15

MC

Not to URLNotify: Corresponds to RefNr or TransID, depending on whether RefNr is transmitted or not.

Status

a..50

M

OK (URLSuccess) or FAILED (URLFailure)

Description

ans..1024

M

Further details in the event that payment is rejected. Please do not use the Description but the Code parameter for the transaction status analysis!

Code

an8

M

Error code according to Paygate Response Codes (A4 Error codes)

UserData

ans..1024

O

If specified at request, Paygate forwards the parameter with the payment result to the shop.

QRCodeUrl

ans..80

C

Pix QR Code image link

QRCodeID

ans..254

C

Alternative code for mobile users to complete the payment when they cannot scan the code

ExpirationDate

ans10

C

Last date to pay the PagBrasil Pix.

Format: MM/DD/YYYY

ExpirationTime

ans5

C

Maximum time within the expiration date the PagBrasil Pix will be allowed to be paid.

Format: HH:MM.

mid

ans..30

M

MerchantID, assigned by Computop

PayID

an32

M

ID assigned by Paygate for the payment, e.g. for referencing in batch files as well as for capture or credit request.

XID

an32

M

ID for all single transactions (authorisation, capture, credit note) for one payment assigned by Paygate

TransID

ans..64

M

TransactionID provided by you which should be unique for each payment

refnr

ans..30

O

Merchant’s unique reference number

Status

a..50

M

OK (URLSuccess) or FAILED (URLFailure)

Description

ans..1024

M

Further details in the event that payment is rejected. Please do not use the Description but the Code parameter for the transaction status analysis!

Code

an8

M

Error code according to Paygate Response Codes (A4 Error codes)

UserData

ans..1024

O

If specified at request, Paygate forwards the parameter with the payment result to the shop.

QRCodeUrl

ans..80

C

Pix QR Code image link

QRCodeID

ans..254

C

Alternative code for mobile users to complete the payment when they cannot scan the code

ExpirationDate

ans10

C

Last date to pay the PagBrasil Pix.

Format: MM/DD/YYYY

ExpirationTime

ans5

C

Maximum time within the expiration date the PagBrasil Pix will be allowed to be paid.

Format: HH:MM.

AmountAuth

n..10

M

Authorized amount in the smallest currency unit (e.g. BRL Centavos)

AmountCap

n..10

M

Captured amount in the smallest currency unit (e.g. BRL Centavos). Used to check whether the total amount has been captured.

AmountCred

n..10

M

Credited amount in the smallest currency unit (e.g. BRL Centavos)

PaymentDate

dttm

M

Date when the PagBrasil Pix was paid by the customer. Format: YYYY-MM-DD.

MerchantID

ans..30

M

MerchantID, assigned by Computop. Additionally this parameter has to be passed in plain language too.

TransID

ans..64

M

TransactionID provided by you which should be unique for each payment

refnr

ans..30

O

Merchant’s unique reference number

Amount

n..10

M

Amount in the smallest currency unit (e.g. EUR Cent). Please contact the Computop Helpdesk, if you want to capture amounts <100 (smallest currency unit).

Currency

a3

M

Currency, three digits DIN / ISO 4217, e.g. EUR, USD, GBP. Only BRL permitted. Please find an overview here: A1 Currency table

MAC

an64

M

Hash Message Authentication Code (HMAC) with SHA-256 algorithm. Details can be found here:

• HMAC Authentication (Request)

• HMAC Authentication (Notify)

UserData

ans..1024

O

If specified at request, Paygate forwards the parameter with the payment result to the shop.

URLNotify

ans..256

M

Complete URL which Paygate calls up in order to notify the shop about the payment result. The URL may be called up only via port 443. It may not contain parameters: Use the UserDataparameter instead.

Common notes:

• Before follow-up actions (capture / credit / reversal) are carried out on an existing transaction, the first Notify must have been answered by the shop.

• Fraudster may just copy the encrypted DATA-element which are sent to URLFailure and send the DATA to URLSuccess/URLNotify. Therefore ensure to check the "code"-value which indicates success/failure of the action. Only a result of "code=00000000" should be considered successful.

Name

ans..128

M

Name of the customer

AddrStreet

ans..46

M

Customer's street name (Optional, if agreed with PagBrasil and Computop)

AddrCity

ans..40

M

Customer's town/city (Optional, if agreed with PagBrasil and Computop)

AddrZip

ans..8

M

Customer's post code (Optional, if agreed with PagBrasil and Computop)

AddrState

a2

M

Abbreviation of the customer’s Federal State. See the following table for the Federal States of Brazil. (Optional, if agreed with PagBrasil and Computop)

TaxNumber

n11/n14

M

In Brazil there are two kinds of tax numbers:

CPF for persons and CNPJ for companies.

CPF: 11 characters without separators, e.g. 12312312312

CNPJ: 14 characters without separators, e.g. 12345678000123

eMail

ans..128

M

Customer's email address (Optional, if agreed with PagBrasil and Computop)

Phone

ans..40

M

Customer's phone number (Optional, if agreed with PagBrasil and Computop)

OrderDesc

ans..768

M

Description of purchased goods, unit prices etc.

ArticleList

ans..254

M

Description of the goods purchased.

Example: ProductName; Quantity+ProductName;Number

The product and the quantity are indicated on the customer’s bill.

Expiration

n..3

O

Number of days (0 - 5), which the PEC Flash® payment slip is valid. If you do not use this parameter the default value configured within PagBrasil dashboard will be used.

ReqId

ans..32

O

To avoid double payments or actions (e.g. by ETM), enter an alphanumeric value which identifies your transaction and may be assigned only once. If the transaction or action is submitted again with the same ReqID, Computop Paygate will not carry out the payment or new action, but will just return the status of the original transaction or action.

Please note that the Computop Paygate must have a finalized transaction status for the first initial action (authentication/authorisation). This does not apply to 3-D Secure authentications that are terminated by a timeout. The 3-D Secure Timeout status does not count as a completed status in which the ReqID functionality on Paygate does not take effect. Submissions with identical ReqID for an open status will be processed regularly.

Notice: Please note that a ReqID is only valid for 12 month, then it gets deleted at the Paygate.

Custom

ans..1024

O

"Custom"-parameter is added to the request data before encryption and is part of encrypted "Data" in Computop Paygate request. By this they are protected against manipulation by a consumer.

The Custom-value is added to the Computop Paygate response in plain text and the "|" is replaced by a "&". By this you can put a single value into Custom-parameter and get multiple key-value-pairs back in response for your own purpose.

Please find a sample here: Custom

mid

ans..30

M

MerchantID, assigned by Computop

PayID

an32

M

ID assigned by Paygate for the payment, e.g. for referencing in batch files as well as for capture or credit request.

XID

an32

M

ID for all single transactions (authorisation, capture, credit note) for one payment assigned by Paygate

TransID

ans..64

M

TransactionID provided by you which should be unique for each payment

refnr

ans..30

O

Merchant’s unique reference number

Status

a..50

M

OK (URLSuccess) or FAILED (URLFailure)

Description

ans..1024

M

Further details in the event that payment is rejected. Please do not use the Description but the Code parameter for the transaction status analysis!

Code

an8

M

Error code according to Paygate Response Codes (A4 Error codes)

UserData

ans..1024

O

If specified at request, Paygate forwards the parameter with the payment result to the shop.

OrderID

ans15

M

Corresponds to RefNr or TransID, depending on whether RefNr is transmitted or not.

TransactionID

ans..17

O

The payment generated code which the shopper needs to show at the lottery store for paying in CASH.

It will be returned in case of successful Authorization Request.

CompanyID

ans..10

O

Company code to be used in the order confirmation page for the shopper, as part of payment instruction information to the lottery store

Note

ans..254

O

Payment instructions that contains a Portuguese text detailing exactly where the customer can pay and which information he will need to provide to the agent. PagBrasil recommends merchants to use this element "payment_instructions" on their confirmation page instead of mounting the text from XML elements (company_code, payment_id, customer_taxid).

mid

ans..30

M

MerchantID, assigned by Computop

PayID

an32

M

ID assigned by Paygate for the payment, e.g. for referencing in batch files as well as for capture or credit request.

XID

an32

M

ID for all single transactions (authorisation, capture, credit note) for one payment assigned by Paygate

TransID

ans..64

M

TransactionID provided by you which should be unique for each payment

refnr

ans..30

O

Merchant’s unique reference number

Status

a..50

M

OK (URLSuccess) or FAILED (URLFailure)

Description

ans..1024

M

Further details in the event that payment is rejected. Please do not use the Description but the Code parameter for the transaction status analysis!

Code

an8

M

Error code according to Paygate Response Codes (A4 Error codes)

UserData

ans..1024

O

If specified at request, Paygate forwards the parameter with the payment result to the shop.

TransactionID

ans..17

O

The payment generated code which the shopper needs to show at the lottery store for paying in CASH.

It will be returned in case of successful Authorization Request.

CompanyID

ans..10

O

Company code to be used in the order confirmation page for the shopper, as part of payment instruction information to the lottery store

Note

ans..254

O

Payment instructions that contains a Portuguese text detailing exactly where the customer can pay and which information he will need to provide to the agent. PagBrasil recommends merchants to use this element "payment_instructions" on their confirmation page instead of mounting the text from XML elements (company_code, payment_id, customer_taxid).

AmountAuth

n..10

M

Authorized amount in the smallest currency unit (e.g. BRL Centavos)

AmountCap

n..10

M

Captured amount in the smallest currency unit (e.g. BRL Centavos). Used to check whether the total amount has been captured.

AmountCred

n..10

M

Credited amount in the smallest currency unit (e.g. BRL Centavos)

PaymentDate

dttm

M

Date when the PEC Flash was paid by the customer. Format: YYYY-MM-DD.

Custom

ans..1024

O

"Custom"-parameter is added to the request data before encryption and is part of encrypted "Data" in Computop Paygate request. By this they are protected against manipulation by a consumer.

The Custom-value is added to the Computop Paygate response in plain text and the "|" is replaced by a "&". By this you can put a single value into Custom-parameter and get multiple key-value-pairs back in response for your own purpose.

Please find a sample here: Custom

MerchantID

ans..30

M

MerchantID, assigned by Computop. Additionally this parameter has to be passed in plain language too.

PayID

an32

M

ID assigned by Paygate for the payment, e.g. for referencing in batch files as well as for capture or credit request.

Expiration

n1

M

Number of days that should be added to the present expiration date (maximum 5)

MAC

an64

M

Hash Message Authentication Code (HMAC) with SHA-256 algorithm. Details can be found here:

• HMAC Authentication (Request)

• HMAC Authentication (Notify)

mid

ans..30

M

MerchantID, assigned by Computop

PayID

an32

M

ID assigned by Paygate for the payment, e.g. for referencing in batch files as well as for capture or credit request.

XID

an32

M

ID for all single transactions (authorisation, capture, credit note) for one payment assigned by Paygate

TransID

ans..64

M

TransactionID provided by you which should be unique for each payment

Status

a..50

M

OK (URLSuccess) or FAILED (URLFailure)

Description

ans..1024

M

Further details in the event that payment is rejected. Please do not use the Description but the Code parameter for the transaction status analysis!

Code

an8

M

Error code according to Paygate Response Codes (A4 Error codes)

OrderID

ans15

M

Corresponds to RefNr or TransID, depending on whether RefNr is transmitted or not.

PaymentSlipLink

ans..256

C

Complete URL to the PDF document, which presents the payment slip with barcode. Only with Boleto Bancário.

QRCodeUrl

ans..80

C

Pix QR Code image link. Only with PIX

QRCodeID

ans..254

C

Alternative code for mobile users to complete the payment when they cannot scan the code. Only with PIX

ExpirationDate

ans10

C

Last date to pay the PagBrasil Pix. Only with PIX

Format: MM/DD/YYYY

ExpirationTime

ans5

C

Maximum time within the expiration date the PagBrasil Pix will be allowed to be paid. Only with PIX

Format: HH:MM

OrderID

ans15

M

Corresponds to RefNr or TransID, depending on whether RefNr is transmitted or not.

MerchantID

ans..30

M

MerchantID, assigned by Computop. Additionally this parameter has to be passed in plain language too.

PayID

an32

M

ID assigned by Paygate for the payment to be captured

TransID

ans..64

M

TransactionID provided by you which should be unique for each payment

refnr

ans..30

O

Merchant’s unique reference number

Amount

n..10

M

Amount in the smallest currency unit (e.g. EUR Cent). Please contact the Computop Helpdesk, if you want to capture amounts <100 (smallest currency unit).

Currency

a3

M

Currency, three digits DIN / ISO 4217, e.g. EUR, USD, GBP. Only BRL permitted. Please find an overview here: A1 Currency table

MAC

an64

M

Hash Message Authentication Code (HMAC) with SHA-256 algorithm. Details can be found here:

• HMAC Authentication (Request)

• HMAC Authentication (Notify)

ReqId

ans..32

O

To avoid double payments or actions (e.g. by ETM), enter an alphanumeric value which identifies your transaction and may be assigned only once. If the transaction or action is submitted again with the same ReqID, Computop Paygate will not carry out the payment or new action, but will just return the status of the original transaction or action.

Please note that the Computop Paygate must have a finalized transaction status for the first initial action (authentication/authorisation). This does not apply to 3-D Secure authentications that are terminated by a timeout. The 3-D Secure Timeout status does not count as a completed status in which the ReqID functionality on Paygate does not take effect. Submissions with identical ReqID for an open status will be processed regularly.

Notice: Please note that a ReqID is only valid for 12 month, then it gets deleted at the Paygate.

mid

ans..30

M

MerchantID, assigned by Computop

PayID

an32

M

ID assigned by Paygate for the payment, e.g. for referencing in batch files as well as for capture or credit request.

XID

an32

M

ID for all single transactions (authorisation, capture, credit note) for one payment assigned by Paygate

TransID

ans..64

M

TransactionID provided by you which should be unique for each payment

Status

a..50

M

OK (URLSuccess) or FAILED (URLFailure)

Description

ans..1024

M

Further details in the event that payment is rejected. Please do not use the Description but the Code parameter for the transaction status analysis!

Code

an8

M

Error code according to Paygate Response Codes (A4 Error codes)

refnr

ans..30

O

Merchant’s unique reference number

OrderID

ans15

M

Corresponds to RefNr or TransID, depending on whether RefNr is transmitted or not.

MerchantID

ans..30

M

MerchantID, assigned by Computop. Additionally this parameter has to be passed in plain language too.

PayID

an32

M

ID assigned by Paygate for the payment to be credited

TransID

ans..64

M

TransactionID provided by you which should be unique for each payment

Amount

n..10

M

Amount in the smallest currency unit (e.g. EUR Cent). Please contact the Computop Helpdesk, if you want to capture amounts <100 (smallest currency unit).

Currency

a3

M

Currency, three digits DIN / ISO 4217, e.g. EUR, USD, GBP. For PagBrasilOTF and Boleto Bancário only BRL is permitted. Please find an overview here: A1 Currency table

MAC

an64

M

Hash Message Authentication Code (HMAC) with SHA-256 algorithm. Details can be found here:

• HMAC Authentication (Request)

• HMAC Authentication (Notify)

ReqId

ans..32

O

To avoid double payments or actions (e.g. by ETM), enter an alphanumeric value which identifies your transaction and may be assigned only once. If the transaction or action is submitted again with the same ReqID, Computop Paygate will not carry out the payment or new action, but will just return the status of the original transaction or action.

Please note that the Computop Paygate must have a finalized transaction status for the first initial action (authentication/authorisation). This does not apply to 3-D Secure authentications that are terminated by a timeout. The 3-D Secure Timeout status does not count as a completed status in which the ReqID functionality on Paygate does not take effect. Submissions with identical ReqID for an open status will be processed regularly.

Notice: Please note that a ReqID is only valid for 12 month, then it gets deleted at the Paygate.

CredNo

ans..

OC

Not with PagBrasilOTF/Boleto Bancário: Credit number. Will be set to “0” if not transmitted.

RefNr

ans..30

OC

Only with PagBrasilOTF and Boleto Bancário: Reference number (e.g. invoice number) which must be unique for each return shipment

AccBankName

ans..40

O

Bank name of the customer

AccNr

ans..12

O

Customer's account number (must contain a hyphen, e.g. 12345-6)

AccBIC

ans..12

O

Bank sort code or rather branch number of the bank

mid

ans..30

M

MerchantID, assigned by Computop

PayID

an32

M

ID assigned by Paygate for the payment, e.g. for referencing in batch files as well as for capture or credit request.

XID

an32

M

ID for all single transactions (authorisation, capture, credit note) for one payment assigned by Paygate

TransID

ans..64

M

TransactionID provided by you which should be unique for each payment

Status

a..50

M

OK (URLSuccess) or FAILED (URLFailure)

Description

ans..1024

M

Further details in the event that payment is rejected. Please do not use the Description but the Code parameter for the transaction status analysis!

Code

an8

M

Error code according to Paygate Response Codes (A4 Error codes)

RefNr

ans..30

OC

Only with PagBrasilOTF and Boleto Bancário: Merchant’s unique reference number

OrderID

ans15

M

Corresponds to RefNr or TransID, depending on whether RefNr is transmitted or not.

Action

Version

Description

Credit

1.0 / 2.0

Standard version without return of parameter Code

1.x / 2.x

with RefNr (valid for all versions other than 1.0)
