The Paygate enables you to handle the direct debit mandates and payments popular with customers – and is fully compatible with SEPA.

Type

Payments by Direct Debit

Format

Description

a

alphabetical

as

alphabetical with special characters

n

numeric

an

alphanumeric

ans

alphanumeric with special characters

ns

numeric with special characters

bool

boolean expression (true or false)

3

fixed length with 3 digits/characters

..3

variable length with maximum 3 digits/characters

enum

enumeration of allowed values

dttm

ISODateTime (YYYY-MM-DDThh:mm:ss)

Abbreviation

Description

Comment

CND

condition

M

mandatory

If a parameter is mandatory, then it must be present

O

optional

If a parameter is optional, then it can be present, but it is not required

C

conditional

If a parameter is conditional, then there is a conditional rule which specifies whether it is mandatory or optional

MerchantID

ans..30

M

MerchantID, assigned by Computop. Additionally this parameter has to be passed in plain language too.

TransID

ans..35

M

TransactionID which should be unique for each payment.

When using auto-mandate (filling-in of MandateID with TransID or RefNr) the permitted character set is that of the MandateID parameter.

Account

ans..12

O

Within Paygate several EasyCollect accounts can be stored on one MerchantID and controlled by the parameter Account. Each account relates to a specific creditor configuration. By default, first entry will be used. The setup must be agreed with Computop Helpdesk.

Amount

n..10

M

Amount in the smallest currency unit (e.g. EUR Cent). Please contact the Computop Helpdesk, if you want to capture amounts <100 (smallest currency unit).

Currency

a3

M

Currency, three digits DIN / ISO 4217, e.g. EUR, USD, GBP. Please find an overview here: A1 Currency table

MAC

an64

M

Hash Message Authentication Code (HMAC) with SHA-256 algorithm. Details can be found here:

• HMAC Authentication (Request)

• HMAC Authentication (Notify)

ReqId

ans..32

O

To avoid double payments or actions (e.g. by ETM), enter an alphanumeric value which identifies your transaction and may be assigned only once. If the transaction or action is submitted again with the same ReqID, Computop Paygate will not carry out the payment or new action, but will just return the status of the original transaction or action.

Please note that the Computop Paygate must have a finalized transaction status for the first initial action (authentication/authorisation). This does not apply to 3-D Secure authentications that are terminated by a timeout. The 3-D Secure Timeout status does not count as a completed status in which the ReqID functionality on Paygate does not take effect. Submissions with identical ReqID for an open status will be processed regularly.

Notice: Please note that a ReqID is only valid for 12 month, then it gets deleted at the Paygate.

URLSuccess

ans..256

M

Complete URL which calls up Paygate if payment has been successful. The URL may be called up only via port 443. This URL may not contain parameters: In order to exchange values between Paygate and shop, please use the parameter UserData.

Common notes:

• We recommend to use parameter "response=encrypt" to get an encrypted response by Paygate

• However, fraudster may just copy the encrypted DATA-element which are sent to URLFailure and send the DATA to URLSuccess/URLNotify. Therefore ensure to check the "code"-value which indicates success/failure of the action. Only a result of "code=00000000" should be considered successful.

URLFailure

ans..256

M

Complete URL which calls up Paygate if payment has been unsuccessful. The URL may be called up only via port 443. This URL may not contain parameters: In order to exchange values between Paygate and shop, please use the parameter UserData.

Common notes:

• We recommend to use parameter "response=encrypt" to get an encrypted response by Paygate

• However, fraudster may just copy the encrypted DATA-element which are sent to URLFailure and send the DATA to URLSuccess/URLNotify. Therefore ensure to check the "code"-value which indicates success/failure of the action. Only a result of "code=00000000" should be considered successful.

Response

a7

O

Status response sent by Paygate to URLSuccess and URLFailure, should be encrypted. For this purpose, transmit Response=encrypt parameter.

URLNotify

ans..256

M

Complete URL which Paygate calls up in order to notify the shop about the payment result. The URL may be called up only via port 443. It may not contain parameters: Use the UserDataparameter instead.

Common notes:

• Before follow-up actions (capture / credit / reversal) are carried out on an existing transaction, the first Notify must have been answered by the shop.

• Fraudster may just copy the encrypted DATA-element which are sent to URLFailure and send the DATA to URLSuccess/URLNotify. Therefore ensure to check the "code"-value which indicates success/failure of the action. Only a result of "code=00000000" should be considered successful.

Consumer Data

EMail

ans..254

M

Email address of the customer

FirstName

ans..50

M

First name

LastName

ans..50

M

Last name

bdStreet

ans..50

M

Street

bdStreetNr

ans..50

M

Street number

bdZip

ans..50

M

Postcode

bdCity

ans..50

M

Town

bdCountryCode

a..3

M

Country code 2 or 3 characters according to ISO 3166

phone

ans..50

M

Mobile phone of the customer; an OTP value is sent to this mobile number in case agreementScheme=SMS is used

bdGender

a1

M

• M=Male

• F=Female

Mandate Data

contractId

ans..50

O

Underlying contract identifier

contractDescription

ans..50

O

Underlying contract description

businessIdentifier

ans..50

O

Unique SIREN Id of the merchant

agreementScheme

enum

O

The way how the OneTimePassword (OTP) will be forwarded to the customer.

DocumentSignature

enum

O

The stamp is added on the last page of the mandate document.

GoogleAnalyticsConsent

enum

O

Debtor consent to use google analytics

SignatureBySca

enum

O

If "true" customer will be authenticated by AccountIdentificationService.

Sps

enum

O

Allows to identify that WS call comes from SPS

Validation

enum

O

If Validation = TRUE --> ORG / If Validation = FALSE --> OTU

customerType

enum

O

Type of customer

MandateID

ans..35

O

Predefined mandate id. The mandate itself will use this mandate id.

Pattern: ^[a-zA-Z+?()-\s:/.,_'0-9] {1,35}$

MdtSeqType

enum

O

Indicates whether the mandate is a one-off mandate or a mandate for recurring direct debits.

There is no default. The default value depends on merchant configuration.

MdtType

enum

O

Indicates whether the mandate is a business-to-business mandate or a customer-to-business mandate.

There is no default. The default value depends on merchant configuration.

EventToken

enum

O

Creates a new mandate and first direct debit transaction simultaneously.

DueDate

ans10

O

DueDate of this transaction. If missing the current day will be used.

Pattern: YYYY-MM-DD

CustomerId

an1..64

O

Customer identifier submitted by the merchant during a payment

RemittanceInfo

ans..50

O

The RemittanceInfo parameter is required for reconciliation purposes, providing essential customer-visible information on customer bank statements for better tracking and reporting.

• Allowed characters: A..Za..z0..9 / - ? : ( ) . , +

• Diactrics like äöüÄÖÜ, áéíóú, àèìòù, âêîôû, ... are not allowed

signerPositionOccupied

ans..70

O

Title of the signatory's position in the company

template

ans..20

O

Name of a XSLT template to get an individual layout for your EasyCollect form which matches with your shop layout. Details are available here: Corporate PayPage and templates.

UserData

ans..1024

O

If specified at request, Paygate forwards the parameter with the payment result to the shop.

Plain

ans..50

O

A single value to be set by the merchant to return some information unencrypted in response/notify, e.g. the MID.

"Plain"-parameter is part of encrypted "Data" in Computop Paygate and therefore protected against manipulation.

Custom

ans..1024

O

"Custom"-parameter is added to the request data before encryption and is part of encrypted "Data" in Computop Paygate request. By this they are protected against manipulation by a consumer.

The Custom-value is added to the Computop Paygate response in plain text and the "|" is replaced by a "&". By this you can put a single value into Custom-parameter and get multiple key-value-pairs back in response for your own purpose.

Please find a sample here: Custom

mid

ans..30

M

MerchantID, assigned by Computop

PayID

an32

M

ID assigned by Paygate for the payment, e.g. for referencing in batch files as well as for capture or credit request.

XID

an32

M

ID for all single transactions (authorisation, capture, credit note) for one payment assigned by Paygate

TransID

ans..64

M

TransactionID provided by you which should be unique for each payment

Status

a..50

M

OK (URLSuccess) or FAILED (URLFailure)

Description

ans..1024

M

Further details in the event that payment is rejected. Please do not use the Description but the Code parameter for the transaction status analysis!

Code

an8

M

Error code according to Paygate Response Codes (A4 Error codes)

MandateID

ans..35

O

Predefined mandate id. The mandate itself will use this mandate id.

Pattern: ^[a-zA-Z+?()-\s:/.,_'0-9] {1,35}$

MAC

an64

M

Hash Message Authentication Code (HMAC) with SHA-256 algorithm. Details can be found here:

• HMAC Authentication (Request)

• HMAC Authentication (Notify)

UserData

ans..1024

O

If specified at request, Paygate forwards the parameter with the payment result to the shop.

Plain

ans..50

O

A single value to be set by the merchant to return some information unencrypted in response/notify, e.g. the MID.

"Plain"-parameter is part of encrypted "Data" in Computop Paygate and therefore protected against manipulation.

Custom

ans..1024

O

"Custom"-parameter is added to the request data before encryption and is part of encrypted "Data" in Computop Paygate request. By this they are protected against manipulation by a consumer.

The Custom-value is added to the Computop Paygate response in plain text and the "|" is replaced by a "&". By this you can put a single value into Custom-parameter and get multiple key-value-pairs back in response for your own purpose.

Please find a sample here: Custom
